# PART NO. DESCRIPTION
1 W010-0243 ASH PAN WITH LID
2 W325-0028 ASH PAN HANDLE
3 W090-0044 RIGHT FRONT FIREBRICK
4 W090-0045 LEFT FRONT FIREBRICK
5 W090-0039 REAR FIREBRICK - 2 REQUIRED
6 W090-0042 BOTTOM RIGHT FIREBRICK
7 W090-0043 BOTTOM LEFT FIREBRICK
8 W090-0041 RIGHT SIDE FIREBRICK
9 W090-0040 LEFT SIDE FIREBRICK
10 W090-0037 LEFT UPPER FIREBRICK BAFFLE
11 W090-0038 RIGHT UPPER FIREBRICK BAFFLE
12 W018-0063 RIGHT FIBRE BAFFLE
13 W018-0064 LEFT FIBRE BAFFLE
14 KB35 VARIABLE SPEED CONTROL
15 W690-0002 HEAT SENSOR
16 W018-0060 BAFFLE SUPPORT
Contact your dealer for questions concerning prices and avail-
ability of replacement parts. Normally all parts can be ordered
through your Authorized dealer or distributor.
When ordering replacement parts always give the following
information:
1. M
ODEL & SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. P
ART NUMBER
4. D
ESCRIPTION OF PART
5. F
INISH
FOR WARRANTY REPLACEMENT PARTS, A PHOTO-
COPY OF THE ORIGINAL INVOICE WILL BE REQUIRED
TO HONOUR THE CLAIM.
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED.
FOR FURTHER INFORMATION, CONTACT YOUR
AUTHORIZED DEALER.
REPLACEMENTS
# PART NO. DESCRIPTION
22 111KT OUTSIDE AIR KIT
23 NZ 690KT THERMOSTATIC AIR CONTROL KIT
24 NZ 62 CH* CENTRAL HEATING KIT
25 NZ62* BLOWER KIT
26 NZ 220 HOT AIR GRAVITY VENT KIT - 5 FT.
27 GA-566 HOT AIR DISTRIBUTION KIT
28 GA-70 EXTENSION KIT - 5 FT
29 W175-0002* FLEXIBLE PIPE COUPLER - 8" DIA.
30 W010-0067* FLEXIBLE VENT SUPPORT ASSEMBLY
31 NZ-FTS* FLUE TILE SUPPORT ASSEMBLY
32 NZ 220-2* HOT AIR GRAVITY VENT EXTENSION KIT - 5 FT.
C/W INSULATION SLEEVE
33 W410-0005* 10FT FLEXIBLE ALUMINUM AIR VENT - 8" DIA.
(FOR USE WITH NZ62CH)
REPLACEMENT PARTS
ACCESSORIES
34 H333 ARCHED BLACK DOOR C/W HANDLE & GASKET
35 H333G ARCHED GOLD PLATED DOOR C/W HANDLE & GASKET
36 H333SS ARCHED STAINLESS STEEL DOOR C/W HANDLE & GASKET
37 H334 WEBBED BLACK DOOR C/W HANDLE & GASKET
37 H334G WEBBED GOLD PLATED DOOR C/W HANDLE & GASKET
37 H334SS WEBBED STAINLESS STEEL DOOR C/W HANDLE & GASKET
38 NZLPB UPPER & LOWER LOUVRE ASSEMBLY- POLISHED BRASS
38 NZLK UPPER & LOWER LOUVRE ASSEMBLY - BLACK
38 NZLG UPPER & LOWER LOUVRE ASSEMBLY - GOLD PLATED
38 NZLSS UPPER & LOWER LOUVRE ASSEMBLY - SATIN CHROME
39 CFSK-B CAST FIREPLACE SURROUND KIT
40 AK-5 ADAPTER KIT, CAST SURROUND
17 W010-1072 DOOR
C/W GLASS & GASKET
18 W562-0010 DOOR GASKET
19 W562-0016 GLASS GASKET
20 W325-0007 LARGE SPRING HANDLE
21 W325-0002 SMALL SPRING HANDLE
Failure to position the parts in accordance with these diagrams or
failure to use only parts specified approved with this appliance may
result in property damage or personal injury.
!
WARNING
