Controls
1. PC DIGITAL IN (DVI-I)
2. H/P (Headphone out)
Connect a headphone to this socket.
3. PC AUDIO IN
Connect the audio cable from the PC to the PC AUDIO IN of the set.
4. PC ANALOG IN (D-SUB)
5. COMPONENT IN
6. DTV IN
7. AV-IN
8. AV-OUT
9. S-VIDEO IN
Connect the output of the S -VIDEO on the VCR to the S-VIDEO input.
Connect the audio outputs of the S-VIDEO on the VCR to the Audio IN (L(MONO), R).
10. Ant. (Antenna input)
1. ON/OFF Switches TV set on or off.
2. MENU
Displays a menu.
3. + PR - (Programme Up/Down)
Selects a programme or a menu item.
4. + VOL - (Volume Up/Down)
Adjusts the volume./ Adjusts menu settings.
5. TV/AV Selects TV, COMPONENT, VIDEO, S-VIDEO, RADIO(Only when the set is
Radio On.), PC Analog, PC Digital or DTV mode./ Clears the menu from the screen.
6. Power Indicator
Illuminates in red when the TV is in standby mode./ Illuminates in green when the
TV is switched on. Illuminates in amber when the power save mode in PC mode.
(It's possible when the connected computer has a built in power management system
called PowerSaver. This system saves energy by switching the set into a low-power
mode when it has not been used for a certain amount of time.)
7. Remote control sensor
Accepts the IR signal of remote controller.
1 23 4 96
8
75
10
