Supplied Accessories
L Make sure the following accessories are provided with Product.
3. Remote controller
5. Owner’s manual
4. PC ANALOG IN cable
6. PC DIGITAL IN cable
7. PC AUDIO IN cable
2. Batteries (2EA)
Owner’s Manual
Model:
NLT-40W
40" Wide LCD Color TV
→→
Battery installation
uInserting batteries
1. Remove the battery cover by pulling it upward in the direction shown by the arrow.
2. Insert the batteries with correct polarity ( "+" to "+", and "-" to "-" ).
3. Replace the battery compartment cover.
*Install two high-quality 1.5V "AAA" alkaline batteries. Don't mix old batteries with
new batteries.
*Remove batteries when you won't use the remote controller for long time. Liquid
leakage from old batteries may cause operation failure.
uNotes for using remote controller
• Make sure there are no objects between the remote controller and its sensor.
• Don't place the remote control near a heater or in damp place. Strong impact to the
remote control may cause operation failure.
• Signal from the remote control may be disturbed by sun light or other bright light. In
this case, darken the room or move the TV.
1. AC cord
7
Controls
1. ON/OFF Switches TV set on or off.
2. MENU
Displays a menu.
3. + PR - (Programme Up/Down)
Selects a programme or a menu item.
4. + VOL - (Volume Up/Down)
Adjusts the volume./ Adjusts menu settings.
5. TV/AV Selects TV, COMPONENT, S-VIDEO,
PC-ANALOG or PC-DIGITAL mode./ Clears the menu frorn the screen.
6. Power Indicator
Illuminates in red when the TV is in standby mode./ Illuminates in green when the
TV is switched on. Illuminates in blinked when the power save mode(only PC mode).
7. Remote control sensor
Accepts the IR signal of remote controller.
1. PC ANALOG(D-SUB) IN
2. PC DIGITAL(DVI-I) IN
3. PC AUDIO IN
Connect the audio cable from the PC Audo IN of the set.
4. HEADPHONE OUT
Connect a headphone to this socket.
5. Sub Woofer OUT
6. D-TV (720P/1080I) IN
7. COMPONENT IN
8. S-VIDEO IN
9. AV-OUT
10. AV-IN
11. ANT.
