User’s Manual
37
Appendix A: Technical Specifications
All specifications are subject to change without notice.
Specifications 4ch Model 8ch Model 16ch Model
Video
Input
BNCx4, 1.0Vp-p, 75
ohm
BNCx8, 1.0Vp-p, 75
ohm
BNCx16, 1.0Vp-p, 75
ohm
Video Standard
NTSC/PAL switch selectable
Video Operation
Triplex (Live, Record, Playback, Remote, and Internet access)
Main Monitor
BNCx1, 1.0Vp-p, 75 ohm
Call Monitor
- BNCx1, 1.0Vp-p, 75 ohm
Outputs
VGA (Optional)
800x600, 1024x768, 1280x1024 pixels @ 60Hz (Optional)
Picture Refresh Rate
NTSC: 120PPS; PAL: 100PPS (16CH)
Digital Zoom
2x2
Camera Installation
Plug & Play
Audio
Input
RCAx1, Line-In
Output
RCAx1, Line-Out
Recording
Compression Method
MPEG-4 Advanced Simple Profile
Recording Mode
Schedule, Alarm, Motion Detection
Pre-alarm
Yes
Resolution & Rate
NTSC: 30PPS@720x480 pixels; PAL: 25PPS@720x576 pixels
NTSC: 60PPS@720x240 pixels; PAL: 50PPS@720x288 pixels
NTSC: 120PPS@360x240 pixels; PAL: 100PPS@360x288 pixels
Recording Quality
Best Quality, Standard, ezRecord, Extended Record, DSL
Image Size
8K to 20K Byte/Picture
Storage Mode
Linear/Circular
Playback
Playback
Play, Stop, Pause, Rewind, Forward, Search
Playback Speed
Adjustment
Yes (1x, 2x, …32x)
Retrieve
Date/Time, Event
Storage
Built-in HDD
Up to 2 built-in HDDs
