Palsonic HDSTB100 DVR User Manual



Chapter 4: Operations
15
Channel Banner
Channel Banner
You can quickly check the status of current display program by pressing the DSP button.
Press DSP button twice to display EPG information if available.
Indicator
if shows MAIN, it means current operation acts to main picture.
if shows PIP, it means current operation acts to PIP sub-picture.
if shows VCR, it means current operation acts to VCR or 2nd TV picture.
The current logical channel number
Program title
Aspect
Program service provider
Teletext information
The local time
Rating control level
Signal intensity indication
Following event information
Present event information
The current program audio type
Nine Digital
16:9 FULL
Nine Network A
Teletext
2004-6-17 08:36
No Class
MAIN
06:00 -- 09:00 Today
09:00 -- 11:00 MORNINGS WITH KERRI-ANNE
9
MPEG2
Now
Next
Signal
TODAY
EPG (MAIN)
Start
06:00
09:00
Stop
09:00
11:00
Event Name
TODAY
MORNINGS WITH KERRI-ANNE
