5. Place channels in the VCR’s memory.
The first time you turn on the VCR or after a power
interruption, the VCR displays a message on the TV screen
prompting you to AUTO-SEARCH CHANNELS for the VCR.
If the message does not appear, go to step A below. If the
message appears, follow the directions on the screen.
Wait until the channel numbers stop changing. This takes
about one to two minutes. The TV tunes to the lowest
channel found. Then, pressing CHAN up or down selects only
the active channels.
If you ever need to manually set up channels (Channel
Setup) on the VCR because you change cable or antenna
signals:
A. Press MENU to display the VCR MAIN MENU on the TV
screen. If this menu does not appear:
• Make sure the TV is tuned to same channel as the
3CH.4 switch on the VCR or the TV’s video input
(refer to TV’s manual).
• If you use a basic hookup, check the VCR indicator in
display panel — it should be on. Press TV•VCR to
turn it on.
• Check the connections.
B. Press 3 to display the CHANNEL SETUP menu.
C. Press 1 to begin AUTO-SEARCH CHANNELS.
The VCR automatically selects CABLE (cable TV) or
ANTENNA. If you need to change the setting manually,
press 3.
6. Add or remove channels from the VCR’s memory.
You may want to add or remove channels if some of the
channels are not active, have weak signals, or you do not
want to watch them.
It is best to place channels in memory using the AUTO-
SEARCH
CHANNELS feature described above before you add
or remove channels since channels 2-13 are the only ones that
are preset at the factory.
A. Press MENU on the remote to see the VCR MAIN MENU
on the TV screen.
B. Press 3 to display the CHANNEL SETUP menu.
C. Press 2 to display the ADD/REMOVE CHANNEL menu.
D. Follow the directions on the screen.
E. Add or remove more channels by using the CHAN up
and down buttons.
Setting Up the VCR
Startup
VCR MAIN MENU
1 TIMER PROGRAMMING
2 REVIEW PROGRAMS
3 CHANNEL SETUP
AUTO-SEARCH CHANNELS
CONNECT ANTENNA CABLE...
THEN PRESS CH UP
CHANNEL SETUP
1 AUTO-SEARCH CHANNELS
2 ADD/REMOVE CHANNELS
3 TUNING MODE: CABLE
4 CABLE BOX SETUP
0 EXIT TO MAIN MENU
VCR MAIN MENU
1 TIMER PROGRAMMING
2 REVIEW PROGRAMS
3 CHANNEL SETUP
CHANNEL SETUP
1 AUTO-SEARCH CHANNELS
2 ADD/REMOVE CHANNELS
ADD/REMOVE CHANNEL
CH 03
IS PRESENTLY ADDED
PRESS CLEAR TO REMOVE
PRESS MENU TO EXIT
