Operation
Runco VX-8d Installation/Operation Manual 59
PRE
L
IMINAR
Y
You should save changes to any of the following settings to a preset; otherwise they will
be lost when a new input source or resolution is selected:
• Brightness
•Contrast
• Color saturation
•Tint
• Sharpness
•Gamma
• Lamp Settings
• Color temperature and white balance
To select a memory preset, press or to highlight it and press ENTER.
To save the settings for the current input and display mode to the Custom 1 or Custom 2
memory preset, select it, press
or to highlight Save and press ENTER.
To reset the Custom 1 or Custom 2 memory preset to its factory-default state, select it,
press
or to highlight Reset and press ENTER.
InformationSignal / System: Select Information from the Main Menu, then choose either Signal or
System to display information about the current input signal (resolution, frequency, type et
cetera) and installed firmware versions, as well as other information that uniquely identifies
your DHD Controller and display device.
Should you ever need to contact Runco Technical Support, this information will help them
answer your questions or resolve product performance issues.
Field Service / Manufacturing: The Field Service and Manufacturing menus are
password-protected and intended for use only by Runco service personnel and factory
technicians.
To save the settings for the current input and display mode to the
ISF
Night or ISF Day memory preset, select Save ISF Night or Save
ISF Day from the Calibration menu (refer to Save ISF Night/Save
ISF Day on page 62).
Note
Information
Signal
System
Field Service
Manufacturing
Signal
Input Source HDMI 1
Signal Format 1080p/60
Input Resolution 1920x1080
Vertical Freq 59.94 Hz
Horizontal Freq 67.500 kHz
Pixel Clock 148.500 MHz
Color Space REC709
Sync Type Separate
Memory Preset ISF Night
System
Model DHD3
Display Name VX-8d
Output Resolution 1920x1080
Serial Number 00000000
Boot Version 3.0
Firmware Version 3.4
Micro Version 3.3
