- 6 -
Channel Mode
Change the channel mode directly between Added Channels and
Favorite Channels.
The Favorite Channels is enabled only when you set Add to
Favorite.
Fine Tune
(analog channels only)
If the reception is clear, you do not have to fine tune the channel, as
this is done automatically during the search and store operation. If the
signal is weak or distorted, fine tune the channel manually.
Fine tuned channels that have been saved are marked with an
asterisk “*” on the right-hand side of the channel number in the
channel banner.
To reset the fine-tuning, select Reset.
Picture Menu
Mode
Select your preferred picture type.
When connecting a PC, you can only select Entertain and
Standard.
Dynamic: Suitable for a bright room.
Standard: Suitable for a normal environment.
Movie: Suitable for watching movies in a dark room.
Entertain: Suitable for watching movies and games.
Only available when connecting a PC.
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R)
Your television has several setting options for picture quality control.
When connecting a PC, you can only make changes to
Backlight, Contrast, Brightness and Sharpness
Advanced Settings
(available in Standard / Movie mode)
Compared to previous models, new Samsung TVs have a more
precise picture.
When connecting a PC, you can only make changes to Gamma
and White Balance.
Color Space (Auto / Native): Adjusts the range of colors available
to create the image.
White Balance: Adjusts the color temperature for a more natural
picture.
R-Offset / G-Offset / B-Offset: Adjusts each color’s (red, green,
blue) darkness.
R-Gain / G-Gain / B-Gain: Adjusts each color’s (red, green, blue)
brightness.
Reset: Resets the White Balance to it’s default settings.
Gamma: Adjusts the primary color intensity.
Dynamic Contrast (Off / Low / Medium / High): Adjusts the
screen contrast.
Black Tone (Off / Dark / Darker / Darkest): Select the black level
to adjust the screen depth.
Flesh Tone: Emphasize pink “flesh tone”.
Motion Lighting (Off / On): Reduce power consumption by
brightness control adapted motion.
Available in Standard mode only.
Picture Options
When connecting a PC, you can only make changes to the
Color Tone, Size and HDMI Black Level.
Color Tone (Cool / Standard / Warm1 / Warm2)
Warm1 or Warm2 will be deactivated when the picture mode
is Dynamic.
Size: Your cable box/satellite receiver may have its own set of
screen sizes as well. However, we highly recommend you use 16:9
mode most of the time.
16:9: Sets the picture to 16:9 wide mode.
Zoom1: Use for moderate magnification.
Zoom2: Use for a stronger magnification.
Wide Fit: Enlarges the aspect ratio of the picture to fit the entire
screen.
4:3: Sets the picture to basic (4:3) mode.
Do not watch in 4:3 format for a long time. Traces of borders
displayed on the left, right and center of the screen may
cause image retention (screen burn) which are not covered
by the warranty.
Screen Fit (DTV): Displays the full image without any cut-off when
HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p)
signals are inputted.
HD (High Definition): 16:9 - 1080i/1080p (1920x1080), 720p
(1280x720)
Settings can be adjusted and stored for each external device
you have connected to an input on the TV.
Picture Sizes available by Input Source:
Input Source Picture Size
ATV, AV, Component (480i, 480p) 16:9, Zoom1, Zoom2, 4:3
DTV(1080i, 1080p), Component
(1080i, 1080p), HDMI (720p, 1080i,
1080p)
16:9, Wide Fit, 4:3, Screen Fit
Digital Noise Filter (Off / Low / Medium / High / Auto): If the
broadcast signal received by your TV is weak, you can activate the
Digital Noise Filter feature to reduce any static and ghosting that
may appear on the screen.
When the signal is weak, try other options until the best
picture is displayed.
HDMI Black Level (Normal / Low): Selects the black level on the
screen to adjust the screen depth.
Available only in HDMI mode (RGB signals).
Film Mode (Off / Auto): Sets the TV to automatically sense and
process film signals from all sources and adjusts the picture for
optimum quality.
Available in ATV, DTV(interlace), AV, COMPONENT (480i /
1080i) and HDMI (480i / 1080i).
Auto Motion Plus (Off / Clear / Standard / Smooth / Custom /
Demo): Enhances motion in fast moving scenes.
The info screen on your TV displays the resolution and
frequency of the incoming video signal (60Hz). This displayed
frequency is not what the TV is displaying by using the Auto
Motion Plus function.
LED Motion Plus (Off / On): Removes drag from fast scenes with
a lot of movement to provide a clear picture.
Picture Reset
Resets your current picture mode to its default settings.
Reset Picture Mode: Returns all picture values in the currently
selected mode to the default settings.
