14
FWD-42PV1/42PV1P/42PV1A
(b) Color Temp
Syntax Header Category Function Data1 Data2 Data3 Check Sum
Control 0x8C 0x10 Code Table(2-b)[a] 0x03 Code Table(2-c) Code Table(2-b)[b] 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x10 Code Table(2-b)[a] Code Table(2-c) 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Return Data2 Check Sum
Enquiry 0x70 0x00 0x03 Code Table(2-c) Code Table(2-b)[b] 0xXX Completed
Code Table(2-b)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x05 Red Gain 0x00-0x1E Yes Yes Disable Enable
0x06 Green Gain 0x00-0x1E
0x07 Blue Gain 0x00-0x1E
Code Table(2-c)
Format Select
0x03 User1
0x04 User2
0x05 User3
6. Size/Shift
(a) 8Bits Register
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x20 Code Table(3-b)[a] 0x02 Code Table(3-b)[b] 0xXX
Enquiry 0x83 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
