19
FWD-42PV1/42PV1P/42PV1A
Code Table(4-d)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x00 Model Name 0x08-0x09 No Yes Enable Enable
0x01 Serial Number 0x001E8480-0x002DC6BF Yes Yes Enable Enable
(2,000,000_2,999,999)
0x02 Operation Time 0x00000000-0xD693A3FF Yes Yes Enable Enable
(0sec._3,599,999,999sec.)
0x03 Soft Version (Main) 0x0000-0xFFFF No Yes Enable Enable
0x07 Digital 3.3 V 0x00-0xFF No Yes Enable Enable
0x08 MainPower (Vs) 0x00-0xFF No Yes Enable Enable
0x09 Digital 5 V 0x00-0xFF No Yes Enable Enable
0x0A Temp1 0x00-0xFF No Yes Enable Enable
0x0B Temp2 0x00-0xFF No Yes Enable Enable
0x0C Temp3 0x00-0xFF No Yes Enable Enable
0x0D Temp (P/S) 0x00-0xFF No Yes Enable Enable
0x10 Analog9 V 0x00-0xFF No Yes Enable Enable
0x11 Shutdown Log 0x00-0xFF No Yes Enable Enable
0x12 Digital 3.3 V (Failure) 0x00-0xFF No Yes Enable Enable
0x13 Digital 5 V (Failure) 0x00-0xFF No Yes Enable Enable
0x14 Analog 5 V/9 V (Failure) 0x00-0xFF No Yes Enable Enable
0x15 MainPower (Va) 0x00-0xFF No Yes Enable Enable
0x16 AnalogPower 12 V 0x00-0xFF No Yes Enable Enable
* Busy to INPUT should be judged by Busy Non Busy. Busy to INPUT may be incorrectly judged during start when it is judged by only Non Busy.
8. User Reset
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x50 Code Table(5) 0x02 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Code Table(5)
Function Range/Switch code Command
Control Enquiry Standby Power On
0x00 Picture Reset Yes No Disable Enable
0x01 Audio Reset Yes No Disable Enable
0x02 Size Reset Size, Shift, Dot Clock, Phase Yes No Disable Enable
0x03 Picture Reset2 Contrast, Brightness, Chroma, Phase Yes No Disable Enable
