Settings and Adjustments
Setting for the Signal to the Digital
Output
When you select “ON,” set “DOLBY DIGITAL” and
“DTS.”
Switches the methods of outputting audio signals when
you connect a digital component such as a receiver
(amplifier) having a digital connector, an audio
component having a built-in DTS decoder, a DAT or MD
via the DIGITAL OUT OPTICAL or COAXIAL connector
using an optical or coaxial digital connecting cord. For
details on the connection, see page 11.
pDOLBY DIGITAL
Selects output Dolby Digital signals via the DIGITAL OUT
OPTICAL and COAXIAL connectors. You cannot select
this item when you set “DIGITAL OUT” to “OFF.”
D-PCM (Downmix PCM): when you play the Dolby
Digital sound tracks, the output audio signals are mixed
down to 2 channels. With the settings of the item
“DOWN MIX” in “AUDIO SETUP,” you can select
whether the signals conform to Dolby Surround (Pro
Logic) or not.
DOLBY DIGITAL: when the player is connected to an
audio component with a built-in Dolby Digital decoder.
Note
If the player is connected to an audio component lacking a
built-in Dolby Digital decoder, do not set “DOLBY DIGITAL”
in “AUDIO SETUP” to “DOLBY DIGITAL.” Otherwise, when
you play the Dolby Digital sound track, a loud noise or no
sound will come out from the speakers, affecting your ears or
causing the speakers to be damaged.
Settings for Sound (AUDIO SETUP)
pDTS
Selects output DTS signals via the DIGITAL OUT
OPTICAL and COAXIAL connectors. You cannot select
this item when you set “DIGITAL OUT” to “OFF.”
OFF: when the player is connected to an audio
component lacking a built-in DTS decoder.
ON: when the player is connected to an audio
component having a built-in DTS decoder.
Note
Select the setting correctly. Otherwise, no sound or strange
sound will come out from the speakers, affecting your ears or
causing the speakers to be damaged.
Do not play the DTS sound tracks without
connecting the player to an audio component
having a built-in DTS decoder. You cannot hear
the DTS sound unless you connect the player to
an audio component having a built-in DTS
decoder.
When you play the DTS sound track on a CD, a
loud noise may come out from the LINE OUT
(AUDIO 1, 2), 5.1CH OUTPUT and PHONES
connectors, affecting your ears or causing the
speakers or headphones to be damaged.
When you play the DTS sound track on a DVD,
no sounds will come out from the LINE OUT
(AUDIO 1, 2), 5.1CH OUTPUT and PHONES
connectors.
Notes on playing the DTS sound tracks on a CD
• Do not play the DTS sound tracks without connecting the
player to an audio component having a built-in DTS decoder.
The player outputs the DTS signal via the DIGITAL OUT
OPTICAL and COAXIAL connectors even if “DTS” in “AUDIO
SETUP” is set to “OFF” in the setup display, affecting your ears
or causing the speakers to be damaged.
• The DTS indicator on the front panel does not light up even if
the player outputs DTS signal via the DIGITAL OUT OPTICAL
and COAXIAL connectors.
• Set the sounds to “STEREO” when you play the DTS sound
tracks on a CD. (See “Changing the Sounds” on page 29.) If
you set the sounds to “1/L” or “2/R,” no sounds will come out
from the DIGITAL OUT OPTICAL and COAXIAL connectors.
AUDIO SETUP
AUDIO ATT:
AUDIO DRC:
TRACK SELECTION:
DOWNMIX:
DIGITAL OUT:
DOLBY DIGITAL:
DTS:
To set, press , then .
To quit, press .
OFF
STANDARD
OFF
DOLBY SURROUND
ON
D-PCM
OFF
ENTER
SETUP
