Getting Started
CD/DVD player
To S-LINK
To an AC outlet
: Signal flow
TV Hookups
This connection is for listening to the sound through TV
speakers (2ch – L, R). Refer to the instructions supplied
with the component to be connected.
Yellow
White (L)
Red (R)
Yellow
White (L)
Red (R)
TV
Required cords
Audio/video/S-link connecting cord (supplied) (1)
S video cord (supplied) (1)
When connecting the cords, be sure to match the color-coded
cord to the appropriate jacks on the components: Yellow (video)
to Yellow, Red (right) to Red and White (left) to White. Be sure to
make connections firmly to avoid hum and noise.
If your TV has an S-link connector, you can control the CD/DVD
player from the TV. Connect the TV via the S-LINK connector.
If your TV has an S video input connector, connect the
component via the S VIDEO OUT connector using the S video
cord. You will get a better picture.
Refer to the instructions supplied with the TV to be connected.
S-linkS-link
To S VIDEO OUT
To S VIDEO
input
To S-LINK
To LINE
OUT
DOLBY DIGITAL (AC-3)
PCM/DTS/
IN
CONTROL S
DIGITAL OUT S-LINK
OPTICAL COAXIAL
5.1CH OUTPUT
WOOFER
FRONT REAR CENTER
R–AUDIO 2–L
LINE OUT
VIDEO 2
R–AUDIO 1–L VIDEO 1
1
2
S VIDEO
OUT
S VIDEO
COMPONENT VIDEO OUT
VIDEO
AUDIO
INPUT
S-LINK
L
R
Y
P
B
/B–Y P
R
/R–Y
R
L
