2.4 STATION EQUIPMENT
2.4.1 iDCS SERIES EQUIPMENT
iDCS 28D KEYSET (See Figure 2–1)
• 32 character display (2 x 16) with three associated soft keys and
a scroll key
• 28 programmable keys with tri-colored lights
• Four fixed function keys
• Terminal Status Indicator
• Built-in speakerphone
• Eight selectable ring tones
• UP/DOWN buttons for digital control of speaker, handset and
ringer volumes
• Desk- or wall-mounted
• Available in dark gray or light gray
iDCS 18D KEYSET (See Figure 2–2)
• 32 character display (2 x 16) with three associated soft keys and
a scroll key
• 18 programmable keys with tri-colored lights
• Four fixed function keys
• Terminal Status Indicator
• Built-in speakerphone
• Eight selectable ring tones
• UP/DOWN buttons for digital control of speaker, handset and
ringer volumes
• Desk- or wall-mounted
• Available in dark gray or light gray
iDCS 8D KEYSET (see Figure 2–3)
• 32 character display (2 x 16) with three associated soft keys and
a scroll key
• 8 programmable keys with tri-colored lights
• Four fixed function keys
• Terminal Status Indicator
• Built-in speakerphone
• Eight selectable ring tones
• UP/DOWN buttons for digital control of speaker, handset and
ringer volumes
• Desk- or wall-mounted
• Available in dark gray or light gray
Note:This keyset type cannot use keyset daughter boards or the 14 button strip.
2.7
FIGURE 2-1
FIGURE 2-2
FIGURE 2-3
