1.3 MAXIMUM DEVICE QUANTITIES
NOTE: Installing some combinations of these cards will reduce the maximum capacities listed above.
DEVICE TYPE MAXIMUM NOTES
Physical Ports 192 In a 2 cabinet system
Stations
Q Digital
Q Analog
Q IP
160*
160*
120
*Maximum number of stations without
any trunks.Limited by the number of
available universal slots and power supply
units.
Trunks
Q Analog
- Loop Start
Q Digital
- T1/PRI
144*
80
80
96
96/92
*Maximum number of trunks without any
stations.Limited by the number of
available universal slots.
Maximum 4 per system.
Networking Nodes
Q Using QSIG over PRI
Q Using QSIG over IP
5
15
Uses available T1/PRI card slots.
Limited by IP Address Table, MMC 820.
Media Gateway Ports 160
Required to connect an IP phone to a
TDM device including paging and
background music and ports used for net-
working or trunking.
Conferencing Circuits
Q 5 Party Add-On
Q Unsupervised
Q Barge-In
Q Call Record
Q AME
6
6
6
6
6
Six Conference Circuits to be shared by all
of these features.
Common Resources
Q DTMFReceivers
Q DTMF Senders
Q Analog Caller ID Senders/Receivers
Q External Music On Hold (MOH)
16
32
14
2
4 on MCP plus 12 on optional MFM board
All on MCP
Optional RCM2 daughter board
Requires CPE and optional MIS
Paging
Q Audio Output
Q Internal Zones
Q External Zones
1
5
2
1 on MIS daughter card.
(99 members each zone)
Requires customer provided equipment.
Voice Mail / Auto Attendant Ports
Q SVMi-20E
12
System can have only one SVMi-20E card
installed.Any port can be shared as
AA/VM or dedicated to AA or VM.
1.5
