SECTION FOUR
4-6
Tab Down Tab Up Enter Back Read On/Off
All Output
1. Use Tab Up or Tab Down to highlight All in the lower portion of the screen and
press Enter.
2. You are asked if you are sure you want to print all the samples. Press Tab Up or
Tab Down to move the highlight to Yes and press Enter.
View
The view option allows you to retrieve and view a stored sample from a selected group.
The selected sample can also be deleted from this screen. Absolute data is displayed in
the View menu with the current color space and illum/obs selections applied.
View
Group: 1
Sample: 5 of 5
Delete
30.99 -3.26 -24.41
30.13 -3.18 -24.19
31.99 -2.87 -24.63
View Sample Data
1. Press Enter with Group: # highlighted. This activates the editor.
2. Use Tab Up or Tab Down to select the desired group and then press Enter.
3. Use Tab Up or Tab Down to select Sample: # of # and press Enter. This activates
the editor.
4. Use Tab Up or Tab Down to select the sample and then press Enter. The selected
sample data is now displayed.
Deleting Selected Sample
1. Use Tab Up or Tab Down to highlight Delete and then press Enter.
2. You are asked if you are sure you want to delete the displayed sample. Press Tab Up
or Tab Down to move the highlight to Yes and press Enter.
Delete
The Delete option works identical to the Print option. The last stored sample in a group
or a specific group’s samples can be deleted. All stored samples can also be selected for
deletion.
Delete
Group: 1
Stored: 5
Last
Group
All
Last Sample or Group Delete
1. Press Enter with Group: # highlighted. This activates the editor.
2. Use Tab Up or Tab Down to select the desired group and then press Enter.
3. Use Tab Up or Tab Down to highlight Last or Group in the lower portion of the
screen and press Enter.
4. You are asked if you are sure you want to delete the last sample. Press Tab Up or
Tab Down to move the highlight to Yes and press Enter.
All Delete
1. Use Tab Up or Tab Down to highlight All in the lower portion of the screen and
press Enter.
