12-EN
4
Turn the Double Action encoder (iDA-X200 only)
or Rotary encoder (iDA-X300 only) to select an
album, and then press
/ENTER.
The song search mode is activated and songs names are
displayed.
5
Turn the Double Action encoder (iDA-X200 only)
or Rotary encoder (iDA-X300 only) to select a
song and press
/ENTER.
The selected song is played back.
While in the search mode, if you press and hold for at least 2
seconds the search mode is canceled.
In the search mode, pressing will return to the previous mode.
When search is made during M.I.X. play, the M.I.X. play mode will be
canceled.
“NO SONG” will be displayed if there are no songs in the selected
playlist in the PLAYLISTS search mode.
“NO PODCAST” will be displayed if there is no podcast data in the
iPod in the PODCASTS search mode.
“NO A-BOOK” will be displayed if there is no audiobook data in the
iPod in AUDIOBOOKS search mode.
If the iPod’s name is selected in the Playlist Search mode and
/ENTER is pressed, all songs in the iPod are searchable. If you
press and hold
/ENTER for at least 2 seconds, all songs in the
iPod are played back beginning from the first song listed.
The display “NO SUPPORT” is scrolled if text information is not
compatible with this unit.
After selecting [ALL] in the search mode with “*”, press and hold
/ENTER for at least 2 seconds to play back all songs in the iPod
or selected search mode.
If percent skip function is activated in the search mode, a search can
be made quickly by skipping to the specified location. For details,
refer to “Percent Skip Function” on
page 12.
If Alphabet Skip Function is activated in the search mode, a search
can be made quickly by Alphabet skip function to find the desired
artist or song, etc. For details, refer to “Alphabet Skip Function
(Only when iDA-X200 is connected via USB)”on
page 12.
In the search mode, you can scroll the page by pressing and turning
the Double Action encoder. (iDA-X200 only.)
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Percent Skip Function
The unit is provided with a percent skip function for effective searching.
When you use this function in the search mode, you can quickly search
an artist or a song, etc.
If there are 100 songs in your iPod, they are divided into 10 groups
using percentages (shown below).
* You can select to show a percentage of the total stored songs, in 10%
steps.
1
Press FUNC./SETUP repeatedly to choose the
percent skip mode.
<When the unit is connected via USB>
Alphabet skip function Percent skip function
Normal search mode Alphabet skip function
<When the unit is directly connected>
Percent skip function Normal search mode
Percent skip function
2
Press and turn the Double Action encoder.
Each turn of the Double Action encoder to the right will jump
10%, 20% and 100% in ascending order.
Each turn of the Double Action encoder to the left will jump
100%, 90% and 10% in descending order.
Scroll bar display example (if 50% is shown)
1
Press FUNC./SETUP to activate the percent
selection mode.
2
Turn the Rotary encoder to select a designated
percent parameter, and then press
/ENTER.
The percent skip function jumps to the following selected
10%
20%…50%…80%…100% 10%.
The iDA-X300 is available only for the direct connection, and is not
available for the USB connection.
Alphabet Skip Function (Only when
iDA-X200 is connected via USB)
The initial skip function is skipped to the next number, symbol or letter
such as from A to B, B to C.
You can skip in reverse order such as B to A by turning the Double
Action encoder to the left.
1
Press FUNC./SETUP repeatedly to choose the
alphabet skip mode.
Alphabet skip function Percent skip function
Normal search mode Alphabet skip function
2
Press and turn the Double Action encoder.
A list is skipped to the next page or next number, symbol or
letter.
If the Double Action encoder is pressed and turned to the left or
right, the display continuously changes.
The Alphabet Skip Function in the song search mode is available
only when a song search is selected on the Menu select screen.
Number of
song
All 100 songs
%
10th
song
20th
song
... 50th
song
... 80th
song
... 100th
song
10 %
20 %
...
50 %
...
80 %
...
100 %
By using this function on iDA-X200
By using this function on iDA-X300
scroll bar
