External Equipment Connections:
Your TV is equipped with 10 inputs including aerial input, which allows for the
external device connection. These inputs are:
1-Aerial input
2-SCART1 input
3-SCART2 input
4-AV input
5-S-Video input
6-PC input
7-HDMI1 input
8-HDMI2 input
9-YPbPr Component input
10-CI input
You can connect your external device to your TV via these inputs. By pressing the
AV button on your remote control, select the external source input to which you
connected your device.
Side view of TV
9.1-Headphone Connection
The headphones must have
impedance between 8 and
32 ohms and have a 3.5
mm stereo jack plug. Plug
the headphone jack into the
headphone socket of the TV.
9.2-Connecting an external equipment via Scart connection
Sidoe or Rear view of TV
or
or
VCR
DECODER
DVD
SATELLITE RECEIVER
GAME CONSOLE
SCART : To watch the picture of the
broadcast device connected to SCART,
select Scart from the Source menu and
press OK button. (You can watch via
this Scart if the connected device has a
RGB output).
