AVSW-HDMI2X1A
Chapter 2: Overview
2. Overview
2.1 Introduction
Use the HDMI Video Switch to quickly and easily share a single HDMI display with
a Blu-ray
™
player, HD-DVD, Xbox
™
, Wii
™
, PS3
™
, Satellite receiver, etc., from
multiple device inputs to one HDMI output device (monitor, projector, or TV).
You can select the desired input source via the remote control (audio models only)
within the range of 15 feet (5 meters) (depends on model) or push button located
on the switch. You never need to plug and unplug video sources, making your
A/V equipment more convenient, more affordable, and more efficient.
The built-in serial interface allows you to control the Video Switch through a PC,
serial controller device, or home theater system, integrating the whole A/V
environment (depends on model).
2.2 Features
• Allows two or four HDMI sources to be connected to one HDMI display.
• Front-panel buttons enable easy switching.
• Supports IR remote control (depends on model).
• Supports serial remote control (depends on model).
• LEDs show the active status of input Video (+ Audio) sources.
• Supports video resolution up to UXGA (1600 x 1200) / Full HD (1920 x 1080)/
WUXGA (1920 x 1200).
• Compatible with most of the popular screen resolutions to XGA, SXGA, UXGA,
WSXGA, WUXGA system.
• Supports HDCP for content protection.
NOTE: When using HDCP, do not swich ports. If you do, the HDCP will perform
content protection.
• Plug-and-play, no software required.
• HDMI 1.3 compatible.
2.3 What’s Included
Your package should include the following items. If anything is missing
or damaged, contact Black Box Technical Support at 724-746-5500
or info@blackbox.com.
