INSTALLATION AND WIRE
CONNECTION MANUAL
9. SAMPLE SYSTEM
VRX766VD
CeNET
STAND
ALONE
SLAVE
STAND
ALONE
(VCZ625)
(DVH940)
(TTX754/TTX7504z)
(SRK5)
(SRV303)
(DCZ625)
TV Tuner
CeNET cable
(included
the TV tuner)
RCA video cable
(included the TV tuner)
CeNET DVD Changer
5.1 ch Surround
Decoder
CeNET cable
(included the
DVH940)
Front
Speakers
4-Channel
Amplifier
Rear
Speakers
Center speaker
built-in amplifier
Powered sub-woofer
built-in amplifier
(Black)
Digital optical fiber cable (included the DVH940)
RCA cable
(sold separately)
RCA cable
(sold separately)
RCA cable (sold separately)
Digital optical fiber cable
(
DCA-005/008, sold separately)
Set the [SLAVE/STAND ALONE]
switch to the [SLAVE] position.
Set the [CeNET/STAND ALONE] switch
to the [CeNET] position.
(Gray)
(Gray)
RCA video cable (included the VCZ625)
Ferrite clamp
(Included the
DVD changer)
RCA cable
(included
the DVH940)
Red
White
Non fader
output
CeNET Cable
(included the Changer)
CeNET Y-adapter
(CCA-519-601,
sold separately)
CeNET CD Changer
Video
Selector
Yellow
Purple
