11
Using DV, also known as i.LINK, you can connect a
DV-equipped camcorder to the DVB-T VCR/DVD
Recorder using a single DV cable for input and
output of audio, video, data and control signals.
The i.LINK interface is also known as IEEE 1394-
1995.
‘i.LINK’ and the ‘i.LINK’ logo are trademarks.
• The DVB-T VCR/DVD Recorder is only
compatible with DV-format (DVC-SD)
camcorders. Digital satellite tuners and Digital
VHS video recorders are not compatible.
• You cannot connect more than one DV
camcorder at a time to the DVB-T VCR/DVD
Recorder.
• It may not always be possible to control the
connected camcorder via the DV IN jack.
• Audio input to the DV IN jack should be 32 or
48kHz (not 44.1kHz).
• Picture disturbance on the recording may occur
if the source component pauses playback or
plays an unrecorded section of tape, or if the
power fails in the source component, or if the
DV cable becomes disconnected.
- Try switching off the HDMI/DVI device and this
recorder. Next, switch on the HDMI/DVI device
and leave it for around 30 seconds, then switch
on this recorder.
- The connected device’s video input is set correctly
for this unit.
- The connected device is compatible with
720x576i or 720x576p, 1280x720p or 1920x1080i
(i:Interlaced scan mode, p:Progressive scan mode)
video input.
Not all HDCP-compatible DVI devices will work with
this recorder.
- It’s impossible to copy protected-DVD title’s
playback in non-HDCP devices.
What is DV?
HDMI (High Definition Multimedia Interface)
supports both video and audio on a single digital
connection for use with DVD Players, Set-Top
Boxes, and other AV devices. HDMI was developed
to provide the technologies of HDCP (High
Definition Contents Protection). HDCP is used to
protect digital content transmitted and received.
HDMI has the capability to support standard,
enhanced, or high-definition video plus standard to
multi-channel surround-sound audio, HDMI features
include uncompressed digital video, a bandwidth of
up to 5 gigabytes per second, one connector
(instead of several cables and connectors), and
communication between the AV source and AV
devices such as DTVs.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
Additional Information for HDMI
When you connect a HDMI or DVI compatible
device make sure of the followings:
About HDMI
USB is an external bus standard that supports data
transfer rates of 12 Mbps. A single USB port can be
used to connect up to 127 peripheral devices, such
as digital cameras, MP3 players, and removable
storage. USB also supports Plug-and-Play
installation and hot plugging.
- The USB port provides USB 2.0 Full Speed
connectivity and also backword compatibility
with USB 1.1 (USB 1.0) devices.
What is USB (Universal Serial Bus)?
Overview Features
• If you happen to use a bad quality USB cable,
the USB device might not be recognized.
• The compatibility with MP3 players and digital
still cameras is somewhat restricted.
- This DVD Recorder + VCR can playback only
mp3 format contents.
- This DVD Recorder + VCR does not support
the audio contents encrypted by DRM (Digital
Right Management).
• Either USB hub device or hub extension
connectivity is not supported.
• There are lots of kinds of USB devices. Some
of the USB devices mentioned above might
not be compatible with this DVD Recorder +
VCR. In other words, the USB host function of
this product does not guarantee the
compatibility with all of USB devices.
• This DVD Recorder + VCR supports both the
high and full speed USB devices (Does not
support Low speed devices).
INTRODUCTION
