EN
FUNCTIONAL OVERVIEW
FRONT PANEL
REMOTE CONTROL
The buttons with circled numbers can only be
operated with the remote control.
DVD VIDEO PLAYERDVD VIDEO PLAYER
DVD -1710
DIMMERDIMMER
ON / STANDBYON / STANDBY
STILL / PAUSESTILL / PAUSE
PLAYPLAY STOPSTOP
OPEN/ CLOSEOPEN/ CLOSE
DVD
1 2 3 4 6 12 11
14 5
13
23
24
15
16
17
18
20
8
10
7
22
6
1
30
3
27
28
26
25
9
24
5
11
4
29
19
12
21
23
1. ON/STANDBY, (POWER ON/OFF) Buttons [page 15]
2. Disc loading tray
3. OPEN/CLOSE Button [page 15]
4. PLAY Button [page 15]
5. STILL/PAUSE Button [page 15]
6. STOP Button [page 15]
7. Cursor Buttons [page 15]
Use when making settings while watching the display on
a TV screen.
8.
MENU Button [page 15]
9. SETUP Button [page 23]
10. ENTER Button [page 15]
11. G (SKIP UP) Button [page 17]
Plays back from the beginning of the next chapter or
track.
12. H (SKIP DOWN) Button [page 17]
Plays back from the beginning of the current chapter or
track.
13. DIMMER Button [page 15]
14. Display, Remote Sensor Window
15. A-B REPEAT Button [page 18]
16. REPEAT Button [page 17]
17. RANDOM Button [pages 18, 20]
18. ZOOM Button [page 16]
19. CLEAR Button [page 17]
20. ANGLE Button [page 21]
Press to change the camera angle and see the same
sequence being played back from a different angle.
21. RETURN Button [page 20]
22. SEARCH MODE Button [page 17]
23. h (Fast Reverse SEARCH) Button [page 16]
24. g (Fast Forward SEARCH) Button [page 16]
25. SUBTITLE Button [page 21]
Press to select a desired subtitle language.
26. TOP MENU Button [page 15]
27. DISPLAY Button [page 20]
28. AUDIO Button [page 21]
Press to select a desired audio language or sound mode.
29. Numeric Buttons [page 17]
30. MODE Button [page 18, 20]
