Functional overview (cont’d)
Before you start
12
Guide to Displays on the front panel
1. Current status of the unit
: Appears when a disc play
is paused.
: Appears when playing a
disc.
: Appears when the timer
programming has been
set and is proceeding.
: Appears during recording
process.
:
Appears during repeat
play.
:
Appears when a tape is in
the unit.
2. Disc type and Current
status of the unit
:
Appears when an audio CD
or a disc with MP3 files is
inserted in the disc tray.
:
Appears when a DVD disc
is inserted in the disc tray.
Appears when the timer
recording is proceeding in
DVD.
Appears when DVD is in
the timer recording stand-
by mode.
:
Appears when a DVD-R disc
is inserted in the disc tray.
:
Appears when a DVD-
RW disc is inserted in
the disc tray.
:
Appears when the timer
recording is proceeding in
VCR.
Appears when VCR is in
the timer recording stand-
by mode.
:
Appears during VCR to DVD
duplication process.
:
Appears during DVD to VCR
duplication process.
Display message
1
2
3
4
3. Recording speed
Indicates the recording speed of
the disc.
4. Title/Track and Chapter
mark
: Appears when indicating
a title/track number.
: Appears when indicating
a chapter number.
5. Displays the following
•Playing time / remaining time
• Current title / chapter / track
number
• Recording time
• Clock
• Channel number
• VCR tape counter
•OTR remaining time
6. : Appears in the after-
noon with the clock
displaying.
1. Appears when the disc tray is
opening.
2. Appears when the disc tray is
closing or close.
3. Appears when a disc is loading
in the disc tray.
4. Appears when recording data
is writing on to the disc.
1
6
3
5
2
4
