54
VOLUME UP/DOWN
Changes the volume level
of the product, normally
the TV.
ON•OFF Turns
product On or Off.
MUTE Turns off the TV
sound while the picture
remains.
CODE SEARCH For setup.
CHANNEL Up/Down
Changes the channels
TRACK +/- controls DVD/
CD track selection i.e. DVD/
CD Track Skip Up/Down (in
DVD and CD modes).
Button Functions, cont.
Note: The REC button must be pressed TWICE to record from
your VCR. For some brands of VCRs, you might need to press
the REC button once, then press it again for three seconds.
RECORD, PLAY, STOP, REW, FF, PAUSE VCR control buttons
operate your VCR even when the remote is set to operate the
TV. Also operates DVD Scan -/+. Note the VCR keys also
control similar functions of your DVD player when in DVD
Mode.
Some buttons on the remote might have functions that
are referred to by different names on the device you are
controlling. E.G. PREV.CH may be called RECALL, or
CLEAR may be called EXIT. These differences depend
on the brand and model of your product. Also, this
remote can only operate features that exist on your
product. E.G., your product must have previous channel
ability for the PREV.CH button to operate this feature.
ENTER For some TV
models, used after
direct channel number
entry to immediately
change to the selected
channel.
TV, VCR, etc.
Selects product to
be operated.
Red Indicator
Lights when any
button is pressed.
GUIDE displays
satellite or cable
on-screen
program guide.
Button Functions
0-9
Enter numbers for direct
channel selection. Some
products require ENTER to be
pressed after channel
selection.
PREV.CH Returns to
the previously selected
channel.
SLEEP enables the remote
to turn off your TV after a
period of 1 to 99 minutes.
Navigation buttons and
SELECT used to move
through on-screen
menuing and guides. With
some DBS models the DISP
button should be used to
select the highlighted item.
Use the navigation buttons
to move the highlighted
choice up, down, left, or
right.
MENU-PROG
Brings up the main
menu. If you are ready
in the menu system,
press SELECT to select
a highlighted choice.
Use the arrow buttons
to move through the
menu selections.
DISP Display button
shows date and time if
your TV or VCR has
that feature.
PIP, SWAP, INPUT. PIP and
SWAP operate your TV’s
Picture-in-Picture features.
INPUT selects the video input
of your TV.
CLEAR Removes the
on screen display to
return to normal
viewing.
TV/VCR Operates the
same as the TV/VCR or
antenna keys on your
original remotes.
