Rear View
A Region Number A pg. 6
B AC Power Cord A pg. 16
C Cooling Fan
● This prevents the temperature from rising inside the unit.
Do not remove it.
● Install the unit so as not to block the area around the fan.
● The unit may become hot when it is turned off, as the cooling
fan on the rear of the unit is not activated. However, the cooling
fan may be activated in the following cases;
^ In the Automatic Satellite Programme Recording standby
mode (A pg. 48), slightly before the starting time of VPS/PDC
recording (A pg. 45).
^ If you connect the decoder or satellite receiver to [L-2 IN/
DECODER], and if AL-2 SELECTB is set to ADECODERB,
ASAT VIDEOB or ASAT S-VIDEOB. (A pg. 63)
^ When AJUST CLOCKB is set to AONB. (A pg. 77)
(Set AJUST CLOCKB to AOFFB if you mind the noise of the
fan.)
D Digital Audio Output Connectors
[DIGITAL AUDIO OUT (OPTICAL/COAXIAL)] (HDD & DVD
deck only) A pg. 64, 70
E S-video Output Connector [S-VIDEO OUT] A pg. 16
F Audio Output Connectors [AUDIO OUT (LEFT/RIGHT)]
A pg. 16
G Component Video Output Connectors [COMPONENT
VIDEO OUT (Y/P
B
/P
R
)] (HDD & DVD deck only) A pg. 16
H Antenna Input Connector [ANTENNA IN] A pg. 16
I L-1 Input/Output Connector [L-1 IN/OUT] A pg. 16, 62, 69,
70
J L-2 Input/Decoder Connector [L-2 IN/DECODER] A pg. 62,
69, 70
K Antenna Output Connector [ANTENNA OUT] A pg. 16
AUDIOOUT
LEFT
RIGHT
PCM/STREAM
COAXIAL
OPTICAL
COMPONENT
VIDEOOUT
P
P
Y
L-2
L-1
IN/OUT
IN/DECODER
ANTENNA
IN
OUT
B
R
HDD/DVD
HDD/DVD
DIGITAL
AUDIOOUT
S-VIDEOOUT
ACDB
H
K
I J
E
F G
