advanced features 43
Tuner Set
The VCR needs to find, identify and memorise all available stations in your area in order to
record programmes correctly. Once done, pressing the A or B buttons enables you
to jump to the available channels without going via any vacant channels. This channel
search can be done either automatically or manually. You should only need to perform
either of the following procedures if Auto Setup or Preset Download has failed to identify
and record available channels or you have moved to a new area.
Auto Channel Setup
get to the main menu Press m.
perform auto channel set Move the highlight bar to AUTO CH
SET
using the A and B buttons and press O (or E)
twice.
rf and scart connection If you have chosen to connect the
VCR to the TV with both the RF Cable and a 21-pin SCART Cable
(not provided) and the TV set is in its AV mode (see the TV
manual), the
AUTO SET screen will
appear on the TV and remains there for about 4–12 minutes while
the VCR searches for receivable stations. During Auto Channel Set
the
S
mark on the screen moves from left to right.
The caption
SCAN COMPLETED appears at the end of the process for
about 5 seconds.
confirmation screen Once
Auto Channel Set has completed
its search, the confirmation screen will appear showing the
details (
PR = Preset Number, CH = Channel Number and ID =
Station Name) of the TV stations that the process has found.
The first station will have a highlight bar over it and will be
blinking. This screen and the programme currently being
broadcast on the selected station will alternate at 8second
intervals. To view the next channel, press the A and B
buttons to move the highlight bar to the required channel.
return to normal screen Press m.
NOTES ON CHANNEL RECEPTION
incorrect station id In certain reception conditions, station names may not be stored
correctly by the VCR and Auto Guide Program Number Set may not work properly. If the Guide
Program Numbers are not set, entering a PlusCode, may result in an incorrect channel being
recorded.
poor reception The VCR memorises all stations found regardless of their quality. If a station’s
quality is poor, you can delete that station from the memory (see page 45).
AUTO SET
PLEASE WAIT
[MENU]:EXIT
PR
01
02
03
04
05
06
07
CH
26
33
23
30
37
[10]
a k: EDIT
a [x]: DELETE
[MENU]: EXIT
ID
BBC1
BBC2
ITV
CH4
CH5
- - - -
- - - -
PR
08
09
10
11
12
13
14
CH ID
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
[1] a k
[MENU]: EXIT
MAIN MENU
MODE SET
AUTO CH SET
MANUAL CH SET
INITIAL SET
F
