DM-9090 (En)
28
1
Go to step 2 if setting adjustments are not
required.
To fade in and fade out the music.
2
3
4
1 Switch the REC MODE on.
2 Select the setting adjustment mode.
3 Set the selection (by pressing the JOG
DIAL).
Adjust the settings if required.
Recording (DIGITAL input)
Recording is possible using recordable Mini Discs. When this unit is connected with a component equipped with digital output,
such as a CD player, through a digital cord or optical fiber cable, the signal input through the DIGITAL input jack can be recorded
in the digital format (this recording is referred to as digital recording). Enjoy high-quality sound of digital recording!
Preparation
1 Open the write protect tab of the Mini Disc to make it recordable.
7
2 Load the Mini Disc.
3 Check the remaining recording time.
o
4 Set the amplifier’s input selector to the source to be recorded.
Select AUTO or MANUAL.
Select one of “DIGITAL 1, 2 and 3”.
Each press switches the mode.
1 REC MODE : off
2 REC MODE : on (“D.REC LEVEL?” displayed.)
The modes are switched by rotating the JOG DIAL.
1 D. REC LEVEL? : Digital recording level setting.
2 AUTO TIME? : Setting of the time for detecting a no-sound
blank section during automatic track num-
ber marking.
3 AUTO LEVEL? : Setting of the level for detecting a non-
sound blank section during automatic track
number marking.
4 FADE TIME? : Setting of the fading time in fade-in and
fade-out.
5 REC= WRITING? : Setting of the UTOC writing after recording.
Each press switches the mode.
1 ANALOG : Analog “stereo mode”
2 DIGITAL 1 : Coaxial input mode
3 DIGITAL 2 : Optical input mode
4 DIGITAL 3 : Coaxial input mode
5 MONO : Analog “monaural long-play mode”
Each press switches the mode.
1 goes off (AUTO) : Track numbers are marked automatically.
£
2 MANUAL : Track numbers can be marked as desired.
£
÷For details on the setting adjustment modes, see “REC MODE key”.
¢
Press in stop mode.
Each press switches the mode.
1 FADE not lit : Fade mode is off
2 FADE lit : Fade mode is on
÷For details on fade-in and fade-out, see “When FADE TIME? is
displayed” (
∞) and “Faded recording of MD” (º).
DIGITAL recording
REC MODE
/CHARA.
4¢
U PDOWN
PUSH SET
JOG DIAL
4¢
U PDOWN
PUSH SET
JOG DIAL
AUTO/
MANUAL
FADE/
DELETE
REC INPUT
