DM-9090 (En)
54
Specifications
[Format]
System ....................................................................................... Minidisc digital audio system
Laser ........................................................................................... Semiconductor laser
Recording method .................................................................... Field modulation overwrite method
Audio compression................................................................... ATRAC (Adaptive TRansform Acoustic Coding)
Playing rotation ........................................................................ Approx. 400 rpm ~ 900 rpm (CLV)
[D/A conversion]
D/A conversion ......................................................................... 1 Bit (24 bit Fine D.R.I.V.E.)
Oversampling ............................................................................ 8 fs (352.8 kHz)
[A/D converter]
A/D converter............................................................................ 4 th order sigma-delta conversion+ D.R.I.V.E. conversion
Sampling frequency ................................................................. 44.1 kHz
[Digital audio performance]
Frequency responce (playback mode).................................... 8 Hz ~ 20 kHz, ± 1 dB
Signal to noise ratio (playback mode) ................................... More than 110 dB
Dynamic range (playback mode) ............................................ More than 98 dB
Total harmonic distortion (1 kHz, playback mode)............... Less than 0.004 %
Wow & flutter............................................................................ Less than unmeasurable limit
Analog input sensitivity / input impedance .......................... 500 mV / 22 kΩ
Analog output level / output impedance............................... 2.0 V / Less than 300 Ω
Headphone output.................................................................... 20 mW/32 Ω load
Digital input
Coxaial .................................................................................... 0.5 Vp-p / 75 Ω
Optical(Wave length 660 nm) .............................................. - 15 dBm ~ - 21 dBm
Digital output
Coxaial .................................................................................... 0.5 Vp-p / 75 Ω
Optical(Wave length 660 nm) .............................................. - 15 dBm ~ - 21 dBm
[General]
Power consumption ................................................................. 20 W
Dimensions ................................................................................ W : 440 mm (17 - 5 / 16”)
H : 125 mm ( 4 - 15 / 16”)
D : 373 mm (14 - 11 / 16”)
Weight (Net) .............................................................................. 5.4 kg (11.9 lb)
1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
