Recorder Title & Camera Titles
This is the screen for setting or changing the recorder and
the camera titles.
step
1. Select “Recorder Title & Camera Titles” and left-
click.
• The “[Recorder Title & Camera Titles]” screen
appears.
step
2. Enter the desired recorder or camera title to “New
Text.”
• The recorder and the camera titles currently set
are shown in the “Current Text.”
step
3. Select “change” and left-click.
Then new changes are displayed at the recorder
monitor A or B output. Also, the recorder “Camera
Display Mode” must be setup to display camera
titles.
E-mail Setup
This is the screen for setting the information related to the
e-mail server or sender, and for setting the e-mail address of
the receiver.
step
1. Select “E-mail Setup” and left-click.
The “[E-mail Setup]” screen appears.
step
2. (When making the settings to send the e-mail • • •)
Input the desired settings for “SMTP Server (Host
Name or IP),” “POP Server (Host Name or IP),”
“POP User ID,” “POP User Password,” “DNS Server
1 Address,” “DNS Server 2 Address,” “From:,” and
“Recorder ID.”
• The settings currently set are shown in the
“Current Settings.”
The maximum number of characters that can be used to
set the e-mail address is 49.
step
3. To send the test e-mail, select “From Address Test
(send test mail)” and left-click.
step
4. (When attaching alarm recording picture to e-mail •
• •)
Put a check mark on “Picture” checkbox.
• E-mail with the picture which is captured during
alarm recording is sent to the marked user. The
file extension of the picture data file which is
attached to e-mail is “.aap”.
• “Delay time to attachment” is used to determine
the timing of capturing the picture to be
attached. The time period between occurrence
of alarm and capture of the picture can be set
up to 10 seconds.
You can send the picture when the alarm recording is
performed.
A picture is sent via e-mail only when the alarm is
triggered by the recorder's rear termianl inputs. Alarm
recording set by motion does not send a picture by e-mail.
To perform this function, put a check mark on “Sensor.”
When the multiple noti cations are occurred at the same
time, noti cation may be delayed or not all the items may
be noti ed.
When the alarm recording time is shorter than the
speci ed delay time, the picture cannot be attached.
When the multiple alarm signals are input at the same
time, only the picture from the camera corresponding to
the lowest sensor number is attached.
Communications by Web Browser (continued)
