NUMBERS REFER TO DRAWINGS ON PAGE 17
12. Digital Filter 2 LED: Indicates the “Digital Filter 2” outlet pair has power.
13. Video Filter LED: Indicates the “Video Filter” outlet pair has power.
14. High Power 1: Indicates the “High Power 1” outlet pair has power.
15. High Power 2: Indicates the “High Power 2” outlet pair has power.
16. Alphanumeric Display: In normal operation, this eight-character LED alphanumeric display will display the
line voltage. In programming mode, it will display options and settings.
17. Audio Filter: For low current analog audio components such as preamplifiers and tape decks, a special filter
circuit reduces noise from the AC power line that would degrade audio performance.
NOTE: It does not harm video components or digital components to be connected to the analog audio outlet
section. However, for best possible performance, we recommend only plugging in low-current analog
audio components here.
18. Audio Fuse: 2A slow-blow fuse protects the "Audio Filter" from power overload. Replace only with same
type/rating fuse.
19. Digital Filter 1: For digital components such as CD players, DVD players, and satellite receivers, this special
filter circuit is designed to reduce interference from your components such as digital noise from getting in the
rest of your system.
20. Digital Filter 1: For digital components such as CD players, DVD players, and satellite receivers, this special
filter circuit is designed to reduce interference from your components such as digital noise from getting in the
rest of your system.
