11
GB
Connections
CONNECTING TO THE SURROUND SOUND SYSTEM
To VIDEO OUT
Video cable
To AUDIO OUT
Audio cable
To audio input
Connection example
Receiver equipped with
Dolby Pro Logic Surround
To video input
Front speaker
(left)
Front speaker
(right)
Centre speaker
Rear speaker (left)
Rear speaker (right)
WARNING
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an
AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting
Digital Audio Output” on page 21).
ENJOYING DOLBY PRO LOGIC SURROUND SOUND
You can still enjoy the excitement of Surround Sound even if your A/V receiver does not offer Dolby Digital decoding. If your A/V receiver has a Dolby
Pro Logic decoder, refer to the following connection diagram.
Connect one or two rear speakers
Note: The surround effect is greatly
enhanced by using two surround speakers.
TV
With a receiver equipped with Dolby Digital
Connect the equipment the same way as described in “Enjoying Dolby Digital Sound” on the previous page. Refer to that receiver’s owner’s manual
and set the receiver so you can enjoy Dolby Pro Logic Surround sound.
T571 manual (GB) 19/11/01 2:14 pm Page 11
