GB
7
REAR PANEL
IDENTIFICATION OF CONTROLS
Introduction
TV SYSTEM SELECT
You can enjoy NTSC or PAL discs by using your TV SYSTEM SELECT switch to choose the appropriate system.
• If you try to play back PAL disc with NTSC-TV. The player will not playback the disc.
• When the selected TV SYSTEM SELECT switch does not coincide with the system of your TV, normal color picture may not be displayed.
• Select the TV SYSTEM SELECT switch when the power is turned off.
• When you playback NTSC disc with PAL-TV, some discs may produce black bands at the top and bottom of the screen.
Position of TV SYSTEM SELECT switch Connected TV Available disc
PALPAL NTSC/PAL DVD disc
NTSC NTSC NTSC/PAL DVD disc
AUTO MULTI system TV NTSC/PAL DVD disc
S-VIDEO OUT jack
VIDEO OUTPUT SELECT switch
SCART/RGB OUT jack
AUDIO OUT (L/R) jacks
VIDEO OUT jack
12V TRIGGER INPUT jack
By connecting this DVD player to another NAD audio component or system
controller equipped with a 12V trigger output, you can remotely operate
the T571 power ON/OFF.
POWER CORD
Connect to an AC 110-240V, 50/60Hz outlet only.
COAXIAL DIGITAL AUDIO OUT jack
TV SYSTEM SELECT Switch
Refer to explanation below.
OPTICAL DIGITAL AUDIO OUT jack
Remove the dust protection cap from the connector and connect the optical digital cable
(not supplied) firmly so that the configurations of both the cable and the connector
match. Keep the dust protection cap and always reattach the cap when not using the
connector to protect against dust.
Dust protection cap
T571 manual (GB) 19/11/01 2:14 pm Page 7
