Preparation
IMPORTANT: Do not apply pressure to the screen display area which
may compromise the integrity of the display. The manufacturer’s warranty
does not cover user abuse or improper installations.
PREPARING YOUR LCD DISPLAY FOR WALL MOUNTING
We suggest that you keep your display at least 2.36 inches (60 mm) from the
wall to prevent cable interference. Before mounting your display on the wall,
you need to remove the base. For your safety, please use only with UL listed
wall mount bracket with minimum weight of the display without stand. (Please
see page.23/25.) To attach a wall mount bracket to your display:
1. Loosen the screws on the back of the stand and remove the back
cover of the stand.
2. Pull up the stand base from the hinge to remove the stand base from
your display.
3. Secure the wall mount bracket to the back of your display using four
M6 screws, as indicated in the illustration.
200 mm
200 mm
400 mm
200 mm
NOTE
200mm x 200mm (7.87inch x 7.87inch) wall mount bracket & M6 screws
are not included.(32”)
400mm x 200mm (15.75inch x 7.87inch) wall mount bracket & M6
screws are not included.(42”)
After taking the base apart, users must attach the two screw lockers
(marked in the picture) to machine, in order to prevent
gap after hanging on the wall.
