NITIAL SETTING
Main Menu
This section describes the overview of the main menu displayed when you
press [SETUP]. For more details, see the reference page for each item.
The main menu consists of the function setting items below.
Press [SETUP].
EXIT
To exit settings.
You can adjust the picture quality.
(Refer to “Picture Adjustment” on page 24.)
SOUND
You can adjust the sound quality.
(Refer to “Sound Adjustment” on page 25.)
CHANNEL
You can automatically scan the viewable channels
and remove those that are undesired.
(Refer to “Auto Channel Scan” on page 14.)
DETAIL
You can change the display format for closed
caption, which displays the dialogue of a TV program
or other information across the TV screen.
(Refer to “Closed Caption” on page 26.)
Set the viewing limitations.
(Refer to “V-chip” on page 30.)
Adjust the position, stability and clarity of the PC
screen.
(Refer to “PC Settings” on page 33.)
And select the sound input for the HDMI jack if your
TV is connected to a HDMI device.
(Refer to “HDMI Audio” on page 34.)
LANGUAGE
You can change the language (English, Spanish,
French) displayed on the main menu.
(Refer to “Language Selection” on page 15.)
5
•
•
•
•
•
•
Auto Channel Scan
If you switch wires (e.g., between antenna and CATV) or if you move the TV
to a different area after the initial setting, or if you restore the DTV channel
you deleted, you will need to perform auto channel scan.
Before you begin:
Make sure if the unit is connected to antenna or cable.
1
Press [SETUP] to display the main menu.
2
Use [Cursor K
/
L] to select “CHANNEL” , then press
[ENTER].
3
Use [Cursor K
/
L] to select “Autoscan”, then press
[ENTER].
Channel
Channel
Autoscan
Channel List
Manual Register
Antenna
Use [Cursor K
/
L] to select an appropriate option, then
press [ENTER].
Autoscan
Autoscan
Autoscan will rescan all channels.
This may take a while to complete.
Select the destination of "ANT.IN" jack.
Back
Air
Cable
Cable
1hour
Air
Cable
Or
ANT.IN
When aerial antenna is connected, select “Air”.
When connected to CATV, select “Cable”.
Scanning and memorizing of channels start
automatically.
Now the system is scanning for channels, please wait.
Exit
SETUP
72%
Analog channels 10ch
Digital channels 6ch
When the scanning and memorizing are completed,
the lowest memorized channel will be displayed.
5
•
•
•
•
