0C28
–
9
–
LR
AUDIO OUT
1
DIGITAL OUT
COAXIAL
39 403837
ANT.
Press to accept a setting.
32. Arrow buttons
TV Mode:
Press to select a setting mode from the menu on
the TV screen.
Press to select or adjust from a particular menu.
DVD Mode:
Use when making settings while watching the
display on a TV screen.
33.
DISC MENU button
Displays the menus in the DVD.
34.
SELECT button
Press to change to TV mode, external input mode
or DVD mode.
35.
MUTE button
Press the MUTE button to turn off the sound
portion of the TV program. (Volume level display
turns LIGHT RED from LIGHT BLUE.) Press the
MUTE button again or press the VOL(ume) K or
L button to restore sound.
36.
PICTURE button
Press to enter picture adjustment mode.
37.
Power cord
Connect to a standard AC outlet (120V/60Hz).
NOTE: Remove the power cord from the hook to
avoid breaking a wire before you connect
to a standard AC outlet.
38.
AUDIO L/R output jack
Connect to the analog audio input of an external
amplifier or decoder.
NOTE: The AUDIO output jacks (red/white) on
the rear panel serve to give out DVD
sound, not TV sound and external input
sound.
39.
COAXIAL digital audio out jack
Connect to the digital input of an external
amplifier or decoder.
40.
ANT. in jack
Connect to an antenna, cable system, or satellite
system.
17.
SLEEP button
Press the SLEEP button to display the sleep timer
and start the function. The shut off time can be
determined by the number of times you press the
button. (0, 10, 20, 30,..90, 0 minutes)
18. SKIP buttons
Skip chapters or tracks to a desired point.
19. ZOOM Button
Expands the picture to fill the entire screen.
20.
SETUP button
Press to enter or exit the TV menu or DVD setup
mode.
21.
TITLE button
Displays the title menu.
22. CLEAR button
Resets a setting.
23. DISPLAY button
TV Mode:
Press to display the channel number on the
screen. If you press it again, the channel number
will disappear.
DVD Mode:
Displays the current status on the TV screen for
checking purposes.
24.
SEARCH MODE button
Press to locate a desired point.
25.
AUDIO button
Press to select a desired audio language or sound
mode.
26.
SUBTITLE button
Press to select a desired subtitle language.
27. REPEAT button
Repeats playback of the current disc, title, chapter
or track.
28.
ANGLE button
Press to change the camera angle to see the
sequence being played back from a different angle.
29. A-B REPEAT button
Repeats playback of a selected section.
30. RETURN button
Returns to the previous operation.
31. ENTER button
REAR VIEW
[Fig. 3]
