Pioneer DVR-543H-S DVD Recorder User Manual



Before you start
01
11
En
Using DVD-R DL/DVD+R DL discs
DVD-R DL (dual-layer) and DVD+R DL
(double-layer) discs contain two recordable
layers on a single side, giving about 1.8
times the recording capacity of a
conventional single-layer disc. This unit can
record to both DVD-R DL and DVD+R DL
discs.
If you intend to play DVD-R DL (Video
mode) or DVD+R DL discs recorded on
this unit on other DVD recorders/players,
you must finalize them. (Note that some
DVD recorders/players may not play
even finalized DL discs.)
Please read the information provided on
the disc packaging carefully before
purchasing DVD-R DL/DVD+R DL discs:
Confirm the disc version:
Use ver. 3.0, 2 x
to 4 x DVD-R discs.
Confirm the recording speed:
DVD-R
should be compatible with 2 x or 4 x
recording; DVD+R with
2.4 x to 8 x recording.
This logo indicates that the disc is a
DVD-R DL or DVD+R DL disc:
Correct operation has been confirmed
for DVD-R DL discs (ver. 3.0 / 2 x, 4 x)
produced by the following
manufacturers: Mitsubishi Kagaku
Media, Verbatim (as of March 2005).
About DualDisc playback
A DualDisc is a new two -sided disc, one side
of which contains DVD content –video,
audio, etc. –while the other side contains
non-DVD content such as digital audio
material.
The non-DVD, audio side of the disc is not
compliant with the CD Audio specification
and therefore may not play.
It is possible that when loading or ejecting a
DualDisc, the opposite side to that being
played will be scratched. Scratched discs
may not be playable.
The DVD side of a DualDisc plays in this
product. DVD-Audio content will not play.
For more detailed information on the
DualDisc specification, please refer to the
disc manufacturer or disc retailer.
Other disc compatibility
In addition to DVD, this recorder is
compatible with a wide range of disc types
(media) and formats. Playable discs will
generally feature one of the following logos
on the disc and/or disc packaging. Note
however that some disc types, such as
recordable CD (and DVD), may be in an
unplayable format—see below for further
compatibility information.
CD-R/RW compatibility
This recorder cannot record CD-R or CD-RW
discs.
Readable formats: CD-Audio, Video CD,
ISO 9660 CD-ROM* containing MP3,
WMA, JPEG or DivX files.
*
ISO 9660 Level 1 or 2 compliant. CD
physical format: Mode1, Mode2 XA Form1.
Romeo and Joliet file systems are both
compatible with this recorder.
Multi-session playback: Yes (except CD-
Audio and Video CD)
Unfinalized disc playback: CD-Audio
only
R DL
4X/2X
Video CD
Audio CD CD-R CD-RW
