Runco LS-1 Installation/Operation Manual 89
PRE
L
IMINAR
Y
7.1
LS-1 Specifications
Table 7-1 lists the LS-1 specifications.
7. Specifications
Table 7-1. LS-1 Specifications
Signal Compatibility
Video Support: HDMI and DVI with HDCP for digital video, Component
and RGB HDTV (1080p, 1080i, 720p), Component and
RGB EDTV (576p, 480p), Component, Composite and
S-Video SDTV (576i, 480i), RGB SCART with adapter,
NTSC/NTSC 4.43, PAL (B,G)/(D,K)/I/M/N, SECAM
Computer Support: Digital and Analog up to 1920x1080 @ 60Hz,
Macintosh®
Communication: RS-232, IR remote, on-board keypad
Connectivity
(2) HDMI V1.3 with HDCP: HDTV RGB and Component, EDTV, SDTV, HDMI (High
Definition Multimedia Interface) with HDCP (High
Bandwidth Digital Content Protection), DVI via adapter
(1) Component (3 x RCA, gold): HDTV, EDTV, SDTV
SCART RGBS via component and composite inputs
(adapter not included)
(1) RGB (HD15): HDTV, RGBHV, YUV, EDTV
(1) S-Video (4-pin mini-DIN): SDTV
(1) Composite (RCA, gold): SDTV
(1) 3.5mm mini jack: 12V (+/-1.5V) screen trigger (250mA)
(1) 9 pin D-sub: RS-232 for discrete commands and software upgrades
Communication Parameters: 38400 bps, no parity, 8
data bits, 1 stop bit, no flow control
(1) 3.5mm mini jack: IR input for Niles/Xantech compatible IR repeater
systems
Communication Protocol: Conforms to NEC standard IR
protocol, 38-kHz carrier frequency, custom code =
0x06F9
