Using the Settings
81
Using the Settings
KDS-R50XBR1/KDS-R60XBR1
2-637-151-11(1)
D:\WINNT\Profiles\fujii\Desktop\SX_EN_source
_onDT062305\01US07MEN.fm
masterpage:3 columns Right
Accessing the Video Settings
Selecting Video
Options
The Video settings include the following options:
1. Press MENU
2. Highlight
3. Press to select
To highlight an option and to change settings,
press V v B b.
Press to confirm the selection.
To exit the Video settings, press .
MENU
Antenna
Video
Custom settings
Vivid
Standard
Pro
Picture Mode Standard
Iris Max
58
Brightness
31
Color 31
Hue
0
Sharpness
25
Color
Temp. Cool
Noise Reduction Medium
Option Description
Picture Mode
Customized
viewing
Vivid Select for enhanced picture contrast and sharpness.
Standard Select for standard picture settings. Recommended for
home entertainment.
Pro Select to display a picture with minimum
enhancements.
✍ You can alter the Video settings (Picture, Brightness,
Color, etc.) for each Picture Mode and each video
input.
✍ You can set up a Picture Mode (Vivid, Standard, Pro)
independently for each Video input (Video 1-Video 7,
including the Antenna input). Your Picture Mode
settings are automatically saved after each selection.
This allows you to customize the Picture Mode
setting for each type of signal source.
Iris Adjust the contrast levels.
Picture Adjust to increase picture contrast and deepen the color or decrease
picture contrast and soften the color.
Brightness Adjust to brighten or darken the picture.
Color Adjust to increase or decrease color intensity.
Hue Adjust to increase or decrease the green tones.
Sharpness Adjust to sharpen or soften the picture.
z To quickly and easily
change from one
Picture Mode to
another, use PICTURE
on the remote control.
(Continued)
..........................
...............................
......................
