Programming RF Control Options
The RF Setup Window
The RF Setup window opens after selecting RFControl from the Program Menu or
clicking on the shortcut button.
Adjusting Signal and IR Output Options
The RF Setup window enables you to adjust the properties of RF Control by clicking on the intersection of a row and a
column and then selecting from the pull down list box the property you want. All of your devices are displayed. You can
set each device individually to be controlled by clicking on the cell you want to change. After clicking, a list box of
options will appear.
S
IGNAL controls how the MX-950 will send
commands:
IR and RF - Both RF signals and IR com-
mands are sent from the MX950.
The RF signals will also be
issued as IR commands by the
MRF-300.
IR - Only IR commands are sent from
the MX950, as a result the MRF-
300 does not send any com-
mands.
RF - Only RF signals are sent from the
MX950, as a result only IR com-
mands from the MRF-300 are
received by the device.
R
ECEIVER enables you to select which MRF-300
receiver will receive the commands for this
device. Thus, you can send commands to a
device in another location via a second MRF-
300 placed in that location (up to 16 in one
house).
Note: The default setting of the RF ID# is
ID#1. If you do not reset the ID in the receiver
window shown here, set the ID# on the bot-
tom of the MRF-300 to ID#1.
RF Control
