COMPLE TE
CONTROL
™
Creating, Naming and Arranging Devices
A device is the basic grouping of a set of hard buttons and up to 255 soft button pages. You will need one
device group for each remote control that the MX-950 is replacing. You can have a maximum of 255 devices
in your configuration. When you create devices in the Create and Name Devices window, every device is
automatically linked with a jump-link to the device via either the WATCH or the LISTEN menu. If you create
devices manually you have to create a jump link from either the WATCH or the LISTEN menu button to each
device manually.
Open the Create and Name Devices Window
You can open the Create and Name Devices window by clicking on the first item of the Program Menu or by
clicking on the Toolbar icon as shown here:
Creating Devices
1 After the Create and Name devices window appears, select the WATCH or the LISTEN menu from
the Device list box:
2 MX-950 Only: Select the button position you’d like to create a new device name in by clicking on it.
Now, decide if you need a double column or a single column label. A single column label can have
up to 5 characters, a double column label up to 11 characters. When you combine a button, IR
command or Macro programming will be duplicated automatically on both the left and the right
button.
Combine both left and right buttons
into one double column button.
Separate a double column button
into two separate buttons.
TIP - Use combined row LCD buttons to type user friendly labels for important activities.
3 Now, select the LISTEN menu from the Device List box and create all the devices for listening.
