Troubleshooting
Troubleshooting
TV
DVD player
Specifications
Problem Solution
No picture or sound. Check all cable connections.
Make sure that your TV combo is
turned on.
Picture is OK, but no
sound.
Check the volume level and mute
setting.
Sound is OK, but no color. Check the color control and adjust
it. Check the program's color
features because it may be a black
and white movie.
The picture has
overlapped images.
Make sure that the antenna is
installed correctly. If not, adjust
the antenna toward the
broadcasting station.
Picture has snow. Check the antenna and its
connection. If there are problems,
correct them. If all connections are
tight, the problem may be with a
faulty antenna or cable. Check car
traffic or neon signs that may
disrupt the image.
Stripes on picture. Check for interference from other
electronic devices, such as radios
and televisions, and keep
magnetic or electronic devices
away from your TV combo.
Bad stereo or SAP sound. A long distance from the
broadcasting station or
interference from radio waves can
generate bad sound reception. If
so, change the mode to Mono.
Remote control does not
work.
Remove obstacles between the
remote control and the player.
Point the remote control at your
TV combo's IR sensor.
Install fresh batteries.
Your TV combo displays a
black or blue screen.
Check the resolution and
frequency of your computer, and
adjust it to the optimum
resolution for this TV: 1280 × 768
at 60Hz.
No Signal appears on the
screen.
Make sure that the cable is firmly
connected to the computer and
TV.
Image is not clear. Adjust the phase control.
Image is not centered. Adjust the horizontal control.
Problem Solution
No sound Make sure that your TV combo or
amplifier is working correctly.
Make sure that the amplifier is set
to receive DVD signal output.
No image Make sure that your TV combo is
working correctly.
Make sure the color system is set
correctly.
Bad sound quality Make sure that the audio output
mode is set correctly.
Make sure that the audio
connection between your
TV combo and amplifier (if used) is
secure.
Disc cannot be played Make sure that the disc is inserted
with the label facing forward.
Clean the disc.
Moisture has condensed in the
player. Remove the disc and leave
the player on for about an hour to
dry out.
The player does not
operate normally
Disconnect the power plug, then
reconnect it.
Remote control does not
work
Remove obstacles between the
remote control and the player.
Point the remote control at your
TV combo's IR sensor.
Install fresh batteries.
LCD Panel 20" wide TFT LCD
Resolution 1366 × 768
Viewing angle 80°/80°/80°/60°
Contrast ratio 500:1
Brightness (cd/m
2
)
500
Dimension With stand 20.9 × 16.6 × 8.3 inches
(534 × 422 × 210 mm)
Without stand 20.9 × 14.5 × 3.5 inches
(534 × 368 × 90 mm)
Weight 21.3 lbs. (9.8 kg)
TV TV standard NTSC
Tuning system Electronic tuning
system
Frequency range VHF/UHF
Stereo NICAM
CATV 125 channels
Power Input 100-240V AC, 50/60 Hz
Consumption (Max.) 75 W
Sound Output 3 W + 3 W
Terminals A/V in Video, S-Video, Audio
L/R
Component Y, Pb (Cb), Pr (Cr)
PC in D-SUB 15-pin RGB in
HDMI HDMI compliant (type A
connector)
Antenna in F-type
DVD player Signal System NTSC
Applicable disc DVD: 12 cm
CD: 12 cm
Problem Solution
