Installation instructions
11
DX-TVM111
STEP 6 - Mounting the TV to the wall plate
• Place the TV bracket (A) into the slotted flanges of the wall plate (B). The TV can be mounted either (1) vertically, or (2)
with a 5° tilt.
HEAVY! You will need
assistance with this step.
1 - Vertical mount
Note: Attach the TV bracket to the flange that is closest to the wall plate.
2 - Tilt mount
Note: Attach the TV bracket to the flange that is farthest from the wall plate.
