On-Screen Display (HDD deck)
When “SUPERIMPOSE” is set to “AUTO” and ON SCREEN on the
remote control is pressed, various operational indicators appear on
the TV screen. To clear the operational indicators, press ON
SCREEN twice.
When playing back a recorded title
A Title start
B Current playback point
C Title end
D Time scale (This title is an hour and a half long.)
E Play mode
F Elapsed playing time
G Current received (recording) channel position number
(On playback background)
H Recorded title (or play list) number currently being played back
I Name of title currently being played back
J Audio mode
K Live Memory mode (recording)
When watching a program on air
A Possible start point from where Live Memory Playback can be
performed
B Possible start point from where Live Memory Recording can be
performed
(Received channel has changed at this point.)
C Currently viewed point
D Time scale
E Current time
F Current received channel position number
When using Live Memory playback
A Time scale for Temporary Recording
B Current Temporary Recording point
C Current time
D Current playback channel position number
E Time scale for Live Memory Playback
F Current playback point
G Live Memory playback mode
H Current playback time
When recording
A Live Memory Recording point
B Live Memory Recording mode
When pressing REC MODE
(Appears for eight seconds.)
A HDD capacity graph
B Current recording speed
C Remaining HDD time for each recording speed
D Recording speed
When pressing 7 during recording
A Recording time for Instant Timer Recording (ITR) mode
004 FISHING WORLD
0:00 1:00 2:00 01:16:48
FR360
STEREO
12
12
STEREO
ON AIR
11:35AM
11:00 12:00 1:00
STEREO
11:35AM
11:35AM
11:00 12:00 1:00
12
STEREO
11:35AM
11:33AM
11:00 12:00 1:00
12
FR360
FR360
7: 00 XP
10: 00 SP
20: 00 LP
28: 00
36: 00
EP
FR480
ITR 2 : 30
