RQT8950
12
STEP 2 Plug-in Auto Tuning
After pressing [^ DVD POWER] to turn the unit on for the first time,
the unit starts necessary setup.
Preparation
Turn on the television and select the
appropriate video input to suit the
connections to this unit.
1 Press [^ DVD POWER].
2 Press [e,r] to select the language
and press [ENTER].
If you make a mistake, press [RETURN] to return to an earlier
screen.
3 Press [e,r] to select “4:3 TV” or
“16:9 Widescreen TV” and press
[ENTER].
4 Press [e,r] to select “On” or “Off”
and press [ENTER].
If you activate “Quick Start” function, select “On”.
5 Press [e,r] to select “Internal TV
Tuner” or “Input” and press [ENTER].
When you do not set channels on this unit, select “Input”. The
unit then displays “Set Clock Manually” screen. Set the clock
manually (Ô page 13).
(Continued on next page)
Regarding DST (Daylight Saving Time) (Ô page 15)
Legal revision is expected to change the DST period in 2007.
When you use the unit with DST on, the change may cause the
unit’s clock to go behind the actual time. Check the DST setting in
“Set Clock Manually” in the Setup menu, set DST off and reset the
clock precisely if you are using this function.
CH
IN2
DV IN
POWER 8
^ DVD
POWER
Numbered
buttons
ADD/DLT
RETURN
e,r,w,q
ENTER
12CH
2 CH 1
* REC
About “Quick Start” function
If you set Quick Start to on, you can start recording to
DVD-RAM about 1 second after you press [^ DVD POWER]
to turn the unit on and then sequentially press [* REC].
The following happens when you have selected “On”.
• Power consumption in standby mode increases because
power is supplied to the unit.
English
Español
Français
Press ENTER
Pulse ENTER
Appuyer sur ENTER
Select Language
Seleccione el idioma
Sélection de Langue
Aspect Ratio Selection
Select TV type and press ENTER.
(Please refer to Operation Instruction
for details)
4:3 TV
16:9 Widescreen TV
16:9
4:3
Quick Start setting
The unit can be turned on faster, in about
1 second. Please note that Quick Start
mode slightly increases power
consumption when the unit is off.
(See Operation Instructions for details)
Turn Quick Start on ?
On
Off
Default Recording Source
Please select the source from which this
unit will record each time it is turned
on. Note: Selecting "Internal TV Tuner"
will start the Auto Channel Clock
Settings process.
This one time process takes a few minutes.
Internal TV Tuner
Input
