Panasonic DMR-ES16 DVD Recorder User Manual



RQT8950
46
Specifications
Recordable discs:
DVD-RAM:
Ver. 2.0
Ver. 2.1/3X–SPEED DVD-RAM Revision 1.0
Ver. 2.2/5X–SPEED DVD-RAM Revision 2.0
DVD-R:
for General Ver. 2.0
for General Ver. 2.0/4X–SPEED DVD-R Revision 1.0
for General Ver. 2.x/8X–SPEED DVD-R Revision 3.0
for General Ver. 2.x/16X–SPEED DVD-R Revision 6.0
for DL Ver. 3.0
for DL Ver. 3.x/4X–SPEED DVD-R for DL Revision 1.0
DVD-RW:
Ver. 1.1
Ver. 1.x/2X–SPEED DVD-RW Revision 1.0
Ver. 1.x/4X–SPEED DVD-RW Revision 2.0
Ver. 1.x/6X–SPEED DVD-RW Revision 3.0
+R:
Ver. 1.0
Ver. 1.1
Ver. 1.2
Ver. 1.3
for DL Ver. 1.0
+RW:
Ver. 1.1
Ver. 1.2/4X–SPEED
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
Playable discs:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format, DivX
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format, DVD Video Recording format
+R +R DL (Double Layer)
+RW DVD-Video
DVD-AUDIOCD-Audio (CD-DA)
Video CD CD-R/CD-RW (CD-DA, Video CD, MP3, JPEG,
DivX)
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification
Class 1 LASER Product
Wave length: 780 nm (CDs)
662 nm (DVDs)
Laser power: No hazardous radiation is emitted with the
safety protection
Television system
TV system: NTSC system, 525 lines, 60 fields
Antenna reception TV Channel: 2 ch–69 ch
input: CATV Channel: 1 ch–125 ch
RF converter output:Not provided
Quick Start for Recording (Quick Start : ON)
1 Sec. Quick Start for Recording on DVD-RAM*
* From the power off state, recording on DVD-RAM starts about 1
second after first pressing the Power button and then sequentially
pressing the REC button (Quick Start Mode).
Video system
Audio system
Note
Specifications are subject to change without notice.
User memo:
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours or 8 hours
Recording system: MPEG2 (Hybrid VBR)
Input: LINE (pin jack) ×2,
S connector ×2
1.0 Vp-p; 75
Y: 1.0 Vp-p; 75
C: 0.286 Vp-p; 75
Output: LINE (pin jack) ×1,
S connector ×1
1.0 Vp-p; 75
Y: 1.0 Vp-p; 75
C: 0.286 Vp-p; 75
Component video
output:
Y, P
B, PR x 1
(480p/480i)
Y: 1.0 Vp-p; 75
P
B: 0.7 Vp-p; 75
P
R: 0.7 Vp-p; 75
Recording system: Dolby Digital (2ch)
Analog Input: LINE (pin jack) ×2
Reference input: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Input impedance: 47 k
Analog Output: LINE (pin jack) ×1
Reference output: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Output impedance: 1 k
(Load impedance: 10 k)
Number of channels: Recording: 2 channels
Playback: 2 channels
Digital Output: Digital audio optical output connector
×1
(PCM, Dolby Digital, DTS)
DV Input: IEEE 1394 Standard, 4 Pin: 1 pc
Regional Code: # 1
Clock unit: Quartz-controlled 12-hour digital display
Operating temperature range: 5 °C to 40 °C (41 °F to 104 °F)
Operating humidity range: 10 % to 80 % RH (no condensation)
Power supply: AC 120 V, 60 Hz
Power consumption: Approx. 19 W
Dimensions (W × H × D): 430 mm × 58 mm × 248 mm
(16
15
/16 × 2
5
/16 × 9
13
/16)
Mass: Approx. 2.8 kg (6.16 lbs)
Power consumption in standby mode:
approx. 2.0 W (Shipping condition)
approx. 6.1 W
(User setting: Quick Start: On)
The model number and serial number of this product can be found
on either the back or the bottom of the unit.
Please note them in the space provided below and keep for future
reference.
MODEL NUMBER DMR-ES16
SERIAL NUMBER
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
