Pioneer DVR-510H DVD Recorder User Manual



Controls and displays
03
21
En
Remote control
1 ONE TOUCH COPY
(page 57)
Press to start One Touch Copy of the currently playing
title to DVD or the HDD. See also the
Note on copying
on
the following page.
2 Remote control indicator
Lights when setting up the remote control for use with a
TV (page 101) and when setting the remote control mode
(page 90).
3
STANDBY/ON
Press to switch the recorder on/into standby.
4
OPEN/CLOSE
Press to open/close the disc tray.
5 HDD
(page 25)
Press to select the hard disk (HDD) for recording or
playback.
6 DVD
(page 25)
Press to select the DVD for recording or playback.
7 DVD playback functions
AUDIO
(page 41)
Changes the audio language or channel. (When the
recorder is stopped, press to change the tuner
audio.)
SUBTITLE
(page 41)
Displays/changes the subtitles included in
multilingual DVD-Video discs.
ANGLE
(page 42)
Switches camera angles on discs with multi-angle
scenes.
8 PLAY MODE
(page 38)
Press to display the Play Mode menu (for features such
as search, repeat and program play).
9 Alphanumeric buttons and CLEAR
Use the number buttons for track/chapter/title selection;
channel selection, and so on. The same buttons can also
be used to enter names for titles, discs and so on.
Use
CLEAR
to clear an entry and start again.
10 INPUT SELECT
(page 51)
Press to change the input to use for recording.
11 CHANNEL +/–
(page 26)
Press to change the channel of the built-in TV tuner.
12 VCR Plus+
(page 49)
Press, then use the number buttons to enter a PlusCode
programming number for timer recording.
13 DISC NAVIGATOR
(page 33)
/ TOP MENU
(page 28)
Press to display the Disc Navigator screen, or the top
menu if a DVD-Video disc is loaded.
14 PLAY LIST
(page 77)
/ MENU
(page 28)
Press to switch between Original and Play List content on
VR mode discs, or display the disc menu if a DVD-Video
disc is loaded.
15
///
(cursor buttons) and ENTER
Used to navigate all on-screen displays. Press
ENTER
to
select the currently highlighted option.
16 HOME MENU
(page 30)
Press to display the Home Menu, from which you can
navigate all the functions of the recorder.
17 RETURN
Press to go back one level in the on-screen menu or
display.
18 Playback controls
(page 27)
REV SCAN / FWD SCAN
(page 35)
Press to start reverse or forward scanning. Press
again to change the speed.
PLAY
Press to start playback.
DVD RECORDER
STANDBY/ON ONE TOUCH
COPY
OPEN/CLOSE
TOP MENU MENU
RETURN
DISC NAVIGATOR PLAY LIST
HOME
MENU
DISC
HISTORY
NAVI
MARK
CASE
SELECTION
CHP
MARK
EASY
TIMER
INPUT
SELECT
INPUT
SELECT
ABC
AUDIO
HDD DVD
SUBTITLE ANGLE PLAY MODE
DEF
GHI JKL MNO
PQRS TUV WXYZ
CLEAR
DISPLAY
ENTER
CLEAR
TV CONTROL
CHANNEL
CHANNEL
VOLUME
REC
PREV
PAUSE STOP
OK CM SKIP
REV SCAN PLAY FWD SCAN
NEXT STEP/SLOW
STOP REC
REC MODE TIMER REC
ì
VCR Plus+
+
1 2
4
8
11
14
17
3
5
12
13
15
16
18
19
22
7
20
6
10
21
9
