Rosen Entertainment Systems R5505 DVD Player User Manual



R5505 17
Four-pin
three-wire
power
harness
connector
External
IR sensor
input
Video output
(yellow)
Left and right
audio output
(white = left,
red = right)
Coaxial digital
output
TV
antenna
input
(R5505
only)
Rear Panel Connections
