7-6
Service Mode
Deletion of blocks
This item is password protected.
The delete function is used to clear all data (settings) from an adjustment block.
A delete can be given :
- block by block
or
- for all blocks.
Deleting block by block
The ‘delete a block’function deletes the settings of a selected block.
Highlight ‘Delete a block’with the control disc and press ENTER.
Push the control disc up or down to select the desired adjustment block. Press
ENTER to delete the selected adjustment block. A confirmation menu will be dis-
played.
ENTER will delete the selected block.
EXIT cancels the deletion procedure and returns to the Service mode main menu.
Deletion of all blocks
Highlight ‘delete all blocks’with the control disc and press ENTER.
If you are certain you wish to delete all blocks, press ENTER to confirm, other-
wise press EXIT to return.
Once ENTER is pressed, all block headers and adjustment settings are perma-
nently removed and cannot be restored.
ENTER will select the pointed item.
EXIT returns to the Path Selection main menu.
ADJUST returns to the Operational mode.
ENTER displays the confirmation menu.
EXIT returns to the Service Mode main menu.
ENTER gives a confirmation message before deleting.
EXIT returns to the Path Selection main menu.
MEMORY MANAGEMENT
COPY A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
Select with
then <ENTER>
<EXIT> to return.
or
DELETE A BLOCK
DELETE MODE
Nr. Src Fh Fv inp conf
1 1 15.6 50 video FC
2 3 31.2 60 RGB3S RT
3 - 15.6 50 intern FC
4 2 31.5 50 RGB3S FC
5 - 33.7 60 intern FC
6
7
8
Select with
then <ENTER>
<EXIT> to return.
or
DELETE BLOCK
The selected block
will be deleted !
<ENTER> to confirm
<EXIT> to cancel
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
Select with
then <ENTER>
<EXIT> to return.
or
DELETE ALL BLOCKS
DELETE ALL BLOCK
All block
will be deleted !
<ENTER> to confirm
<EXIT> to cancel
