Quick Setup
Table 3-1 gives a quick overview of the Q-650i installation process. The sections following
this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step Procedure
For Details, Refer to
page...
1
Choose a location for the projector 13
2
If installing a CineWide-equipped projector: Install
AutoScope lens motor or fixed CineWide base plate
(optional)
19
3
Mount the projector 26
4
Connect signal sources to the Q-650i 27
5
Connect external controller to RS-232 port (optional) 31
6
Connect 12-volt trigger output to AutoScope lens motor or
other equipment (optional)
32
7
Apply power to the projector 33
8
Primary lens adjustments: focus, projected image size
(zoom) and position (shift)
16, 34
9
Change the OSD Language (optional) 35
10
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation
35
11
Install CineWide anamorphic lens (optional) 36
12
CineWide lens adjustments: position, pitch (angle),
geometry and focus
38
13
Projector calibration: adjust the following for each input;
save settings when finished:
• Aspect ratio
•Brightness
•Contrast
• Color level
•Tint
• Input position
46
