Q-650i Series Installation/Operation Manual 45
PRE
L
IMINAR
Y
4.3
Using the On-Screen
Menus
1. Press the MENU button on the remote control to display the Main Menu.
2. There are six menus. Press or to select a sub-menu.
3. Press or to select a sub-menu item.
4. For each sub-menu item, the currently-selected value appears in white text or is
otherwise highlighted. Press
or to choose a setting for that item, or press
ENTER to go to another sub-menu.
5. Press MENU to return to the previous menu.
6. From the Main Menu, press MENU to turn off the OSD menu.
The Q-650i OSD menus are arranged hierarchically, as shown in Figure 4-1. Depending
on the selected input source and signal characteristics, some menu options may not be
available.
Figure 4-1. Q-650i OSD Menu Structure
Main
Aspect Ratio
16:9, Letterbox, 4:3,
VirtualWide, Cinema or
V-Cinema
Memory
Recall Memory
Save Settings
Save ISF
Brightness
0 ... 50* ... 100
Contrast
Color
Tint
Sharpness
Noise Reduction
Overscan Off, Crop or Zoom
Input Select
HDMI 1, HDMI 2, RGB,
Comp. 1, Comp. 2, Video,
S-Video or SCART
PIP Select
Off, HDMI 1, HDMI 2, RGB,
Comp. 1, Comp. 2, Video,
S-Video or SCART
Resync (press ENTER to execute)
Advanced
Color Space
Auto, REC709, REC601,
RGB-PC or RGB-Video
Video Standard Auto, NTSC, PAL or SECAM
Gamma 1.8, 2.0, 2.2, 2.35 or 2.5
Color Temperature
5500K, 6500K, 7500K or
9300K
DLP Frame Rate Auto, 48 Hz, 50 Hz or 60 Hz
Color Gamut
Auto, REC709, SMPTE-C,
EBU, Native, DCI or PCE
ConstantContrast Low, Medium, High or Off
Adaptive Contrast On or Off
RGB Adjust
Red / Green / Blue Offset
Red / Green / Blue Gain
Fine Sync
V. Position
H. Position
Phase
Tracking
Sync Level
PCE
Hue (Red / Yellow / Green /
Cyan / Blue / Magenta)
Saturation (Red / Yellow /
Green / Cyan / Blue / Magenta)
Level (Red / Yellow / Green /
Cyan / Blue / Magenta)
Runco Smart Color (RSC) (On
or Off)
White Balance (Red / Green /
Blue Gain)
System
Input Enable On or Off for each source
PIP Position
Top Left, Top Right, Bottom
Left, Bottom Right,
Picture-by-Picture or
Split Screen
Menu Position
Top Left, Top Right, Bottom
Left, Bottom Right or Center
Translucent Menu
0% (opaque), 25%, 50% or
75%
Blank Screen Logo, Black, Blue or White
Auto Power Off
On or OffAuto Power On
Rear Projection
Ceiling Mode Auto, On or Off
Logo Display
On or Off
Power On Chime
Control
HD 1 Key
HDMI 1, HDMI 2, RGB,
Comp. 1, Comp. 2, Video,
S-Video or SCART
HD 2 Key
HD 3 Key
CineWide Off, CineWide or AutoScope
Trigger 1
AutoScope, Lamp, 4:3 or
RS-232
Trigger 2
Language
English, French, German, Italian, Spanish, Swedish,
Portuguese or Russian
Service
Model Name
(read-only)
Unit Serial Number
Software Version
LED Driver Version
Active/PIP Source
Pixel Clock
Signal Format
H/V Refresh Rate
Factory Reset
Reset Everything?
(Yes or No)
Blue Only On or Off
Test Patterns On or Off
Altitude Auto or High
