52 Vistage™ Series Flat-Panel Display Installation/Operation Manual
PRE
L
IMINAR
Y
Color Space: Select Color Space from the Service menu to choose the color space of
the source signal for HDMI, RGB, and component connections.
• The default setting, Auto, functions as follows:
• HDMI: If the Auxiliary Video Information (AVI) infoframe contains color space and/or
range data, the DHD Controller uses that information. Otherwise, for RGB sources,
the DHD Controller uses the RGB-Video color space. For component SDTV and
EDTV resolutions, REC601 is used. For other component video resolutions,
REC709 is used.
• RGB: If Hsync or Vsync signals are present, the DHD Controller uses the RGB-PC
color space. Otherwise, REC601 is used for SDTV and EDTV sources, and REC709
for all other sources.
• Component: For SDTV and EDTV resolutions, the DHD Controller uses the
REC601 color space. For all other resolutions, REC709 is used.
In most cases, the Auto setting determines the correct color space to use. If it does not,
you can force the DHD Controller to use a specific color space. Choose one of the
following:
• REC709 sets the color space matrix to that defined in ITU-R BT.709.
• REC601 sets the color space matrix to that defined in ITU-R BT.601.
• RGB-PC uses RGB color space and sets black at 0,0,0 RGB and white at
255,255,255 RGB, assuming an 8-bit image.
• RGB-Video uses RGB color space and sets black at 16,16,16 RGB and white at
235,235,235, assuming an 8-bit image, to correspond to the luminance values defined
in digital component standards.
Miscellaneous: Select Miscellaneous from the Service menu to set the following options:
• Language: Select Language from the Miscellaneous menu and press the up- or
down-arrows to select the OSD Language (English, Français, Deutsch, Italiano,
Español, Svenska, (Simplified Chinese), (Traditional Chinese),
Português, (Russian), (Japanese) or (Korean).
•OSD Timer: Select OSD Timer from the Miscellaneous menu to set the OSD Timer,
which controls how long the menus remain on-screen after selecting them. Select from
5 to 60 seconds, in one-second increments. Or, set the timer to 0 (disabled) if you want
the menus to remain on-screen indefinitely.
•OSD Messages: When you select a new aspect ratio, input source or memory preset,
the DHD Controller briefly displays an on-screen message confirming your new
selection. To prevent the display of these messages, select OSD Messages from the
Miscellaneous menu to and set it to Off.
•Blank Screen Color: Select Blank Screen Color from the Miscellaneous menu to
select the color that appears when no incoming signal is present. The range is from 0
to 255 inclusive for each color component (red, green and blue).
• Sidebar Color: Select Sidebar Color from the Miscellaneous menu to change the
color of the inactive image area. The range is from 0 to 255 inclusive for each color
component (red, green and blue). The inactive image area is on either side of the active
image area when using the 4:3 aspect ratio.
• Film Mode: Use Film Mode to smooth out moving images from interlaced,
standard-definition (SD) sources. In most cases, the DHD Controller detects the proper
“pull-down” rate and vertical frequency. However, if your source is jittery and/or tearing
you may want to enable Film Mode to ensure stable processing for that source.
